1. Press [Main Menu] twice, scroll to parameter
group 5-** Digital In/Out and press [OK].
Illustration 5.9 6-15 Terminal 53 High Ref./Feedb. Value
2. Scroll to parameter group 5-1* Digital Inputs and
press [OK].
5 5
Illustration 5.10 Digital In/Out
3. Scroll to 5-10 Terminal 18 Digital Input. Press [OK]
to access function choices. The default setting
Start is shown.
Illustration 5.11 Digital Inputs
5.4 International/North American Default
Parameter Settings
Setting 0-03 Regional Settings to International or North
America changes the default settings for some parameters.
Table 5.1 lists those parameters that are effected.
Parameter
0-03 Regional
Settings
0-71 Date Format
0-72 Time Format
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.ctiautomation.net - Email: info@ctiautomation.net
36
®
VLT
Operating Instructions
14.6% 0.00A
Main Menu
2-** Brakes
3-** Reference / Ramps
4-** Limits / Warnings
5-** Digital In/Out
14.7% 0.00A
Digital In/Out
5-0* Digital I/O mode
5-1* Digital Inputs
5-4* Relays
5-5* Pulse Input
14.7% 0.00A
Digital Inputs
5-10 Terminal 18 Digital
Input
[8]] Start
International North American
Default Parameter Default Parameter
Value Value
International North America
YYYY-MM-DD MM/DD/YYYY
24h 12h
MG20M902 - VLT
AQUA Drive
Parameter
1(1)
1-20 Motor Power
[kW]
1-21 Motor Power
[HP]
1-22 Motor Voltage 230 V/400 V/575 V
1-23 Motor
Frequency
3-03 Maximum
Reference
3-04 Reference
Function
4-13 Motor Speed
High Limit [RPM]
1(1)
See Note 3
5-**
4-14 Motor Speed
High Limit [Hz]
See Note 4
4-19 Max Output
Frequency
4-53 Warning Speed
High
5-12 Terminal 27
Digital Input
5-40 Function Relay Alarm
6-15 Terminal 53
High Ref./Feedb.
Value
1(1)
6-50 Terminal 42
5-1* Output
14-20 Reset Mode
22-85 Speed at
Design Point [RPM]
See Note 3
22-86 Speed at
Design Point [Hz]
Table 5.1 International/North American Default Parameter Settings
Note 1: 1-20 Motor Power [kW] is only visible when 0-03 Regional
Settings is set to [0] International.
Note 2: 1-21 Motor Power [HP], is only visible when 0-03 Regional
Settings is set to [1] North America.
Note 3: This parameter is only visible when 0-02 Motor Speed Unit is
set to [0] RPM.
Note 4: This parameter is only visible when 0-02 Motor Speed Unit is
set to [1] Hz.
Changes made to default settings are stored and available
for viewing in the quick menu along with any
programming entered into parameters.
1. Press [Quick Menu].
2. Scroll to Q5 Changes Made and press [OK].
®
is a registered Danfoss trademark
International North American
Default Parameter Default Parameter
Value Value
See Note 1 See Note 1
See Note 2 See Note 2
208 V/460 V/575 V
20-1000 Hz 60 Hz
50 Hz 60 Hz
Sum External/Preset
1500 RPM 1800 RPM
50 Hz 60 Hz
1.0 - 1000.0 Hz 120 Hz
1500 RPM 1800 RPM
Coast inverse External interlock
No alarm
50 60
100 Speed 4-20mA
Automatic reset x 10 Infinite auto reset
1500 RPM 1800 RPM
50 Hz 60 Hz
