About Frequency Converter P...
2.
Scroll to parameter group 5-1* Digital Inputs and
press [OK].
14.7%
Digital In/Out
5-0* Digital I/O mode
5-1* Digital Inputs
5-4* Relays
5-5* Pulse Input
Illustration 5.10 Digital In/Out
3.
Scroll to 5-10 Terminal 18 Digital Input. Press [OK]
to access function choices. The default setting
Start is shown.
14.7%
Digital Inputs
5-10 Terminal 18 Digital
Input
[8]] Start
Illustration 5.11 Digital Inputs
5.4 International/North American Default
Parameter Settings
Setting 0-03 Regional Settings to [0] International or [1]
North America changes the default settings for some
parameters. Table 5.1 lists those parameters that are
effected.
Parameter
International
default parameter
value
0-03 Regional
International
Settings
1-20 Motor Power
See Note 1
[kW]
1-21 Motor Power
See Note 2
[HP]
1-22 Motor Voltage 230 V/400 V/575 V
1-23 Motor
50 Hz
Frequency
3-03 Maximum
50 Hz
Reference
3-04 Reference
Sum
Function
4-13 Motor Speed
1500 RPM
High Limit [RPM]
See Note 3 and 5
VLT
®
AutomationDrive Operating
Instructions
0.00A
1(1)
4-14 Motor Speed
5-**
High Limit [Hz]
See Note 4
4-19 Max Output
Frequency
4-53 Warning Speed
High
5-12 Terminal 27
Digital Input
5-40 Function Relay No operation
6-15 Terminal 53
High Ref./Feedb.
Value
6-50 Terminal 42
0.00A
1(1)
Output
5-1*
14-20 Reset Mode
Note 1: 1-20 Motor Power [kW] is only visible when 0-03 Regional
Settings is set to [0] International.
Note 2: 1-21 Motor Power [HP], is only visible when 0-03 Regional
Settings is set to [1] North America.
Note 3: This parameter is only visible when 0-02 Motor Speed Unit is
set to [0] RPM.
Note 4: This parameter is only visible when 0-02 Motor Speed Unit is
set to [1] Hz.
Note 5: The default value depends on the number of motor poles. For
a 4 poled motor the international default value is 1500 RPM and for
a 2 poled motor 3000 RPM. The corresponding values for North
America is 1800 and 3600 RPM, respectively.
Changes made to default settings are stored and available
for viewing in the quick menu along with any
North American
programming entered into parameters.
default parameter
value
North America
See Note 1
See Note 2
208 V/460 V/575 V
60 Hz
60 Hz
External/Preset
1800 RPM
®
MG33AM02 - VLT
is a registered Danfoss trademark
Parameter
International
default parameter
value
50 Hz
132 Hz
1500 RPM
Coast inverse
50
No operation
Manual reset
Table 5.1 International/North American Default Parameter Settings
1.
Press [Quick Menu].
2.
Scroll to Q5 Changes Made and press [OK].
25.9%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q5 Changes Made
Q6 Loggings
Illustration 5.12 Q5 Changes Made
North American
default parameter
value
60 Hz
120 Hz
1800 RPM
External interlock
No alarm
60
5
Speed 4-20 mA
Infinite auto reset
0.00A
1(1)
37
5
