1.4 Send Reset signal (via Bus, Digital I/O, or
[Reset] key). The test step is passed when the
motor becomes operational again.
The commissioning test is passed if all four test steps 1.1,
1.2, 1.3 and 1.4 are passed.
Case 2: Automatic Restart of Safe Stop is wanted and
allowed (that is, Safe Stop only where 5-19 Terminal 37
Digital Input is set to [3], or combined Safe Stop and MCB
112 where 5-19 Terminal 37 Digital Input is set to [7] PTC 1
& Relay W or [8] PTC 1 & Relay A/W):
2.1 Remove the 24 V DC voltage supply to
terminal 37 by the interrupt device while the
frequency converter drives the motor (that is
mains supply is not interrupted). The test step is
passed when
•
the motor reacts with a coast, and
•
the mechanical brake is activated (if
connected)
•
the alarm "Safe Stop [A68]" is displayed
in the LCP, if mounted
2.2 Reapply 24 V DC to terminal 37.
The test step is passed if the motor becomes operational
again. The commissioning test is passed if both test steps
2.1 and 2.2 are passed.
NOTE
See warning on the restart behaviour in 1.6.1 Terminal 37
Safe Stop Function
WARNING
The Safe Stop function can be used for asynchronous,
synchronous and permanent magnet motors. Two faults
can occur in the power semiconductor of the frequency
converter. When using synchronous or permanent magnet
motors a residual rotation can result from the faults. The
rotation can be calculated to Angle = 360/(Number of
Poles). The application using synchronous or permanent
magnet motors must take this residual rotation into
consideration and ensure that it does not pose a safety
risk. This situation is not relevant for asynchronous motors.
