62 MDS entraNET 900 System Guide (Preliminary)
1. Launch a TFTP server on a PC connected either directly or via a
LAN to the Ethernet port (
towards the directory containing the firmware image file.
2. Connect to the entraNET Management System by whichever means
is convenient: Browser or Telnet via the
via the port.
COM1
3. Go to the entraNET MS Reprogramming Menu.
(Main Menu>Maintenance Menu>Reprogramming Menu)
4. Fill in the information for the:
• TFTP Host Address—IP Address of server (host com-
puter) running TFTP server.
• Retrieve File—Name of file (
from the TFTP server holding the firmware file.
5. Pull the firmware file through the TFTP server into the entraNET
unit.
(Main Menu>Maintenance Menu>Reprogramming Menu>Retrieve File)
Status messages on the transfer are posted on the entraNET Man-
agement System screen.
NOTE: The uploaded firmware image file replaces the
"Inactive Image" file will be automatically verified.
6. Reboot the transceiver.
Main Menu>Maintenance Menu>Reprogramming Menu>Reboot Device
7. Test the transceiver for normal operation.
End of Procedure
) of the transceiver. Point the server
LAN
, or Terminal emulator
LAN
filename.ipk)
MDS 05-4055A01, Rev. A
to be pulled
