Endpoint Listing Menu
(Access Points Only)
This list shows all of the non-entraNET 900 Ethernet devices that are
known to the transceiver and is equivalent to the ARP table of IP
devices.
-==========================================================================-
MAC Address IP Address
00:b0:24:b9:e9:94 10.3.145.49
00:b0:24:4d:db:15 10.3.128.124
00:c0:4f:41:e3:8b 10.3.145.84
00:50:08:14:35:ff <Unknown>
00:b0:24:41:02:b0 10.3.128.25
00:20:bf:07:47:b2 10.3.145.123
00:50:08:17:4e:2c 10.3.144.27
00:40:8b:b4:b1:39 <Unknown>
00:c0:59:01:00:8c <Unknown>
00:c0:59:01:23:00 <Unknown>
00:50:97:45:fc:14 10.3.145.88
00:50:97:e0:7f:71 10.3.144.47
00:c0:4f:41:df:70 10.3.128.245
00:10:4b:27:cb:d5 10.3.145.41
Number of endpoints: 285
Page 1 of 21
Press Enter to continue, Escape to quit
Select a letter to configure an item, <ESC> for the prev menu
Figure 2-30. Endpoint Listing Menu
(Lists all equipment attached to REMOTE transceivers in the network)
• MAC Address—Hardware address of endpoint device.
• IP Address—IP Address of endpoint device.
• AgeTime—Time, in minutes, remaining before the device
(address) will be deleted from the table.
Each transceiver maintains a table with the addresses of the devices
it communicates with. The age time countdown is restarted to 5 min-
utes every time a message to/from that device is detected. If no traf-
fic with that device happens, it then "ages out" of the table. When
traffic is detected it is included again in the table. This optimizes
memory space utilization.
• via Remote—Hardware address of the transceiver connected to
this device.
• RxPkts—Over-the-air data packets received by the transceiver.
and passed on to the endpoint device.
• TxPkt—Number of packets received from the endpoint device and
passed over-the-air.
MDS entraNET 900 System Guide (Preliminary)
Library Admin Office
Endpoint Listing Menu
AgeTime via Remote
3 min 00:05:3d:00:00:35
3 min 00:05:3d:00:00:35
< 1 min 00:05:3d:00:00:35
4 min 00:05:3d:00:00:35
3 min 00:05:3d:00:00:35
3 min 00:05:3d:00:00:35
3 min 00:05:3d:00:00:35
4 min 00:05:3d:00:00:35
4 min 00:05:3d:00:00:35
4 min 00:05:3d:00:00:35
3 min 00:05:3d:00:00:35
3 min 00:05:3d:00:00:35
< 1 min 00:05:3d:00:00:35
3 min 00:05:3d:00:00:35
RxPkts TxPkt
22 3
50 0
9 0
1 0
19 0
21 1
18 0
18 0
197 0
387 0
18 0
33 0
1 0
22 0
53
