View Event Log
Wireless Packet
Statistics
MDS 05-4055A01, Rev. A
-==========================================================================-
Num Date Time
------------------------------------------------------------------------------
==START OF OPERATIONS LOG==
1 28 Dec 2001 23:21
2 28 Dec 2001 23:21
3 29 Dec 2001 20:55
4 29 Dec 2001 20:55
5 29 Dec 2001 20:55
6 29 Dec 2001 20:55
7 29 Dec 2001 20:55
8 29 Dec 2001 20:56
9 29 Dec 2001 20:56
10 29 Dec 2001 20:56
11 29 Dec 2001 20:57
12 29 Dec 2001 20:57
13 29 Dec 2001 20:57
14 29 Dec 2001 20:57
Use Up, Down, Pg-Up, Pg-Dn, Home or End to view log, <ESC> for the prev menu
Figure 2-26. Sample Event Log Screen
Packet Statistics Menu
-==========================================================================-
Wireless Packet Statistics
Packets received 2206
Packets sent
Bytes received
Bytes sent
Packets dropped
Receive errors
Retries
Retry errors
A) Clear Wireless stats
Select a letter to configure an item, <ESC> for the prev menu
Figure 2-27. Sample Packet Statistics Menu
• Packets received—Over-the-air data packets received by
this unit
• Packets sent—Over-the-air data packets sent by this
Remote.
• Bytes received—Over-the-air data bytes received by this
Remote.
• Bytes sent—Over-the-air data bytes sent by this Remote.
• Packets dropped—Received packets dropped as a result
of a lack of buffers.
• Receive errors—Packets that do not pass CRC. This may
be due to transmissions corrupted by RF interference.
• Retries—Number of requests to re-send a data packet
• Retry errors—Packets discarded after exceeding five
retries over-the-air.
• Clear Wireless stats—Resets the statistics counter.
MDS entraNET 900 System Guide (Preliminary)
Library Admin Office
Event Log
Description
Hop Table Write Successful
Scanning Started
Received Beacon OK
Hop Table Write Successful
Expected Sync Established
Hop Sync Established
Association Established
Association Lost
Hop Table Write Successful
Scanning Started
Received Beacon OK
Hop Table Write Successful
Expected Sync Established
Hop Sync Established
Library Admin Office
Packet Statistics Menu
Ethernet Packet Statistics
Packets received
2177 Packets sent
247575 Bytes received
236106 Bytes sent
0 Packets dropped
1 Receive errors
4 Lost carrier detected 0
2
B) Clear Ethernet stats
0
2172
0
161877
0
0
49
