128 MDS entraNET 900 System Guide (Preliminary)
6.3 TECHNICAL SPECIFICATIONS
GENERAL
Temperature Range:
Humidity:
Primary Power:
Supply Current (typical):
Transmit:
Receive:
Sleep:
MTBF:
Size (Excluding mtg. hardware):
Weight:
Case:
Boot Time:
Time Required to Associate
with Access Point:
APPROVALS/HOMOLOGATION
:
EMBEDDED MANAGEMENT SYSTEM
Access Point:
Remote Radios:
DATA CHARACTERISTICS
PORTS (AP):
Ethernet:
Interface Connectors:
Data Rate:
COM1, COM2:
Signaling Standard:
Interface Connectors:
Interface:
–40° C to +70° C (–40° F to 158° F)
95% at +40° C (104° F); non-condensing
6–30 Vdc (13.8 Vdc Nominal)
(8 Watts Maximum @ 1 Watt RF Output)
28 mA @ 13.8 Vdc
100 mA @ 13.8 Vdc
<7 mA @ 13.8 Vdc
35 Years (Telcordia Method 1, Case 3)
1.5" x 6" x 4" (H x W x D)
3.8 x 15.2 x 10.2 cm
0.9 kg / 2 lb (AP)
0.0 kg/0 lb (Remote)
Cast Aluminum
≈ 30 sec
≈ 20 sec
• FCC Part 15.247 (Pending)
• Industry Canada RSS-210 and RSS-139 (Pend-
ing)
• UL/CSA Class 1, Div. 2; Groups A, B, C and D
hazardous locations (Pending)
• Contact MDS for information on availability and
governmental approvals in other countries
• HTTP (Embedded Web server)
• Text-based menu on COM1 serial port
• Telnet
• Command line via COM1 port
RJ-45 Standard
10BaseT
EIA-232/V.24
RJ-45
COM1: DCE / COM2: DTE
MDS 05-4055A01, Rev. A
