Editing Rules
MDS 05-4055A01, Rev. A
Each resulting file should be saved with a different name. We recom-
mend using directories and file names that reflect the location of the unit
to facilitate its identification.
• You may include only parameters you want to change.
• Change only the parameter values.
• Capitalization counts in some field parameters.
(Example: System Mode)
• Comment Fields
a. Edit, or delete anything on each line to the right of the
comment delineator, the semicolon (;).
b. Comments can be of any length, but must be on the same
line as the parameter, or on a new line that begins with a
semicolon character.
c. Comments after parameters included in files exported
from a transceiver do not need to be present in your cus-
tomized files.

2.8.3 Authorization Keys Menu

-==========================================================================-
A) Authorization Key
Authorized Features
Access Point
Dual Remote
Remote Serial Gateway
Remote Ethernet Bridge
MDS NETview MS
Select a letter to configure an item, <ESC> for the prev menu
Figure 2-37. Authorization Key Menu
• Authorization Key—Initiate the entering of an Authori-
zation Key into the transceiver's non-volatile memory.
• Authorized Features—List of authorized features.
In addition to the four transceiver configurations fields, is the
MDS NETview MS
help users monitor system performance, configure network ele-
ments, detect faults and correct problems in the convenience of
an office setting or at any other point in the network.

2.8.4 Radio Test Menu

This area provides several useful tools for installers and maintainers.
You can manually key the transceiver to make measurements of antenna
MDS entraNET 900 System Guide (Preliminary)
Library Admin Office
Authorization Key Menu
enabled
enabled
enabled
enabled
enabled
access control. NETview MS is designed to
71
