resolving common system difficulties using the LEDs, and
other simple techniques.
Table 4-1. Troubleshooting Using LEDs—Symptom-Based
Symptom Problem/Recommended System Checks
PWR LED does not
a. Voltage too low—Check for the proper supply voltage at
turn on.
b. Indefinite Problem—Cycle the power and wait
LINK LED does not a. Network Name of Remote not identical to desired Access
turn on.
b. Not yet associated with an Access Point with the same
c. Poor Antenna System—Check the antenna, feedline and
PWR LED is a. Blinking indicates an alarm condition exists.
blinking.
b. View Current Alarms and Event Log and correct the
c. Blinking will continue until the source of the alarm is
LAN LED does not a. Verify the Ethernet cable is connect at both ends.
turn on.
b. Verify that the appropriate type of Ethernet cable is used:
4.1.2 Troubleshooting Using the Embedded
Management System
If you have looked over and tried the things mentioned in
still have not resolved the problem, there are some additional tools and
techniques that can be used. The embedded Management System is a
good source of information that may be used remotely to provide pre-
liminary diagnostic information, or may even provide a path to cor-
recting the problem.
Table 4-2. Basic Troubleshooting with the entraNET MS
Symptom Problem/Recommended System Checks
Remote does not a. Verify the AP has sufficiently large number in the "Max
associate; stays in
HOPSYNC
b. Verify the correct MAC address is listed in the "Approved
Serial data is slow a. Change Beacon Period to FAST.
with UDP multicast
traffic
the power connector. (10.5–30 Vdc)
(≈ 30 seconds) for the unit to reboot. Then, recheck for
normal operation.
Point—Verify that the system has a unique Network Name.
Network Name.
Check the "Status" of the unit's process of associating with
the Access Point. Use the entraNET Management System.
connectors. Reflected power should be less than 10% of
the forward power reading (SWR 2:1 or lower).
problem if possible.
(See "Using Logged Operation Events" on Page
corrected, for example, a valid IP address is entered, etc.
straight-through, or crossover.
Remotes" parameter of the Network Configuration Menu.
Remotes List" or "Approved Access Points List" of the
Security Configuration menu.
(Radio Configuration Menu)
Table 4-2
92)
Table 4-1and
