CAUTION
RADIO FREQUENCY
INTERFERENCE
POTENTIAL
126 MDS entraNET 900 System Guide (Preliminary)

6.2 DATA INTERFACE CONNECTORS

(Pubs Note: There will be separate sections for the AP and Remote in
the final book. Presently, only the AP is covered.)
Three data interface connectors are provided on the face of the Access
Point transceiver. The first, the LAN Port, is an RJ-45 connector. The
other two use two DB-9 interface connectors that use the RS-232
(EIA-232) signaling standard. Note that the connector for
DCE (Female DB-9) and the
The transceiver meets U.S.A.'s FCC Part 15, Class A limits when used
with shielded data cables.

6.2.1 LAN Port

The LAN Port is used to connect the radio to an Ethernet network. The
transceiver will provide a data link to an Internet Protocol-based (IP)
data network through the radio network's Access Point station. Each
transceiver in the network must have a unique IP address for the network
to function properly.
• To connect a PC directly to the radio's
RJ-45 cross-over cable is required.
• To connect the radio to a Ethernet hub or bridge, use a
straight-through cable.
The connector uses the standard Ethernet RJ-45 cables and wiring. For
custom-made cables, use the pinout information below.
Figure 6-1. LAN Port (RJ-45) Pinout
(Viewed from the outside of the unit)
Table 6-1. LAN Port (IP/Ethernet)
Pin
1
2
3
4
5
6
7
8
Port is DTE (male DB-9).
COM2
LAN
1 2 3 4 5 6 7 8
Functions Ref.
Transmit Data (TX) High
Transmit Data (TX) Low
Receive Data (RX) High
Unused
Unused
Receive Data (RX) Low
Unused
Unused
MDS 05-4055A01, Rev. A
Port is
COM1
port, an RJ-45 to
