46 MDS entraNET 900 System Guide (Preliminary)
• Endpoint Listing
by this AP through associated Remote ports.
(See "Endpoint Listing Menu (Access Points Only)" on
Page 53)
• Remote Performance Listing
See "Remote Performance Listing Menu (Access Points Only)"
(
on Page 54)
RSSI by Zone Menu
This screen displays the strength of RF signals received from the cur-
rently associated Access Point.
Wireless network integrity depends partially on stable radio signal
levels being received at each end of a data link. In general, signal levels
stronger than –80 dBm will provide reliable communication that
includes a 15 dB fade margin.
If you find there is a poor signal level on one zone, check the
tistics Menu section on Page 49
questionable zone to "Skipped" in the Radio Configuration Menu
29) and look for an improvement in the Packet Statistics error rates. If
there is none, return the Zone to "Active."
RSSI measurements and Wireless Packet Statistics are based on mul-
tiple samples over a period of several seconds. The average of these
measurements will be displayed by the entraNET Management System.
-==========================================================================-
Zone #1
Zone #2
Zone #3
Zone #4
Zone #5
Select a letter to configure an item, <ESC> for the prev menu
Figure 2-23. RSSI by Zone Menu
TIP: Under normal circumstances, the signal levels in each zone should
be within a few decibels of each other. If you see one that is signif-
icantly lower or higher, it may be a sign of radio frequency inter-
ference from another signal source on the 900 MHz band.
See "Network Performance Notes" on Page 54
mation.
(AP Display only)—
(Remotes Only)
and record the values. Then, set the
MIS Com. Room
RSSI by Zone Menu
-93 dBm Zone #6
Skipped Zone #7
-98 dBm Zone #8
-99 dBm Zone #9
-97 dBm Zone #10
List of units accessible
(AP Display only)—
Packet Sta-
(Page
-95 dBm
-92 dBm
-88 dBm
-87 dBm
-86 dBm
for further infor-
