Microwave Data Systems MDS entraNET 900 System Manual page 49

MDS 05-4055A01, Rev. A
Table 2-4. Serial Port Application Configuration
MDS entraNET 900
Unit Location
Access Point
Remote Units 1 & 2 (COM2)
Remote Units 3 & 4 (COM2)
MDS entraNET 900 System Guide (Preliminary)
Menu Item Setting
Status Enabled
Baud Rate 9,600
Flow Control Disabled
IP Protocol UDP
Send to Address A multicast IP address such as
224.254.1.1
Send to Port 30011
Receive on Port 30011
Receive on Address 0.0.0.0 (Not Used)
Status Enabled
Baud Rate 2,400
Flow Control Disabled
IP Protocol TCP
Receive on Port 30011
Status Enabled
Baud Rate 9,600
Flow Control Disabled
IP Protocol UDP
Send to Address IP address of the entraNET AP
Send to Port 30011
Receive on Port 30011
Receive on Address 224.254.1.1
(The multicast IP address used
for the AP's Send To Address
above)
41
