CAUTION
RADIO FREQUENCY
INTERFERENCE
POTENTIAL
MDS 05-2806A01, Rev. E.1

6.1 DATA INTERFACE CONNECTORS

Three data interface connectors are provided on the face of the trans-
ceiver. The first, the LAN Port, is an RJ-45 connector. The other two use
two DB-9 interface connectors that use the RS-232 (EIA-232) signaling
standard. Note that the connector for
and the COM2 Port is DTE (male DB-9).
The transceiver meets U.S.A.'s FCC Part 15, Class A limits when used
with shielded data cables.

6.1.1 LAN Port

The transceiver's LAN Port is used to connect the radio to an Ethernet
network. The transceiver provides a data link to an Internet Pro-
tocol-based (IP) network via the Access Point station. Each radio in the
network must have a unique IP address for the network to function prop-
erly.
• To connect a PC directly to the radio's
RJ-45 cross-over cable is required.
• To connect the radio to a Ethernet hub or bridge, use a
straight-through cable.
The connector uses the standard Ethernet RJ-45 cables and wiring. For
custom-made cables, use the pinout information below.
Figure 6-1. LAN Port (RJ-45) Pinout
(Viewed from the outside of the unit)
Table 6-1. LAN Port (IP/Ethernet)
Pin
1
2
3
4
5
6
7
8
MDS iNET 900 Series User's Guide
Port is DCE (Female DB-9)
COM1
LAN
1 2 3 4 5 6 7 8
Functions Ref.
Transmit Data (TX) High
Transmit Data (TX) Low
Receive Data (RX) High
Unused
Unused
Receive Data (RX) Low
Unused
Unused
port, an RJ-45 to
143
