Table 30: GPIO Connections to FPGA U1
FPGA (U1) Pin
BANK 67
BANK 67
BANK 67
BANK 67
BANK 67
BANK 67
BANK 67
BANK 67
BANK 64
BANK 67
BANK 67
Switches
[Figure 2, callouts 30, 33]
The VCU118 evaluation board includes a power on/off slide switch and a configuration
pushbutton switch.
• FPGA Program_B SW4, active-Low (callout 30)
• Power on/off slide switch SW5 (callout 33)
Power On/Off Slide Switch SW5
[Figure 2, callout 33]
The VCU118 board power switch is SW5. Sliding the switch actuator from the off to the on
position applies 12VDC power from the 6-pin mini-fit power input connector J16, normally used
in bench-top applications with the provided power adapter. The green LED DS20 illuminates
when the VCU128 board power switch is on. See
power system. The following figure shows the power connector J16, power switch SW5, and
indicator LED DS20.
UG1302 (v1.0) December 21, 2018
VCU128 Board User Guide
Schematic Net
Name
GPIO LEDs (Active-High) GPIO_LED signals are wired to LED driver U56
BH24 GPIO_LED_0
BG24 GPIO_LED_1
BG25 GPIO_LED_2
BF25 GPIO_LED_3
BF26 GPIO_LED_4
BF27 GPIO_LED_5
BG27 GPIO_LED_6
BG28 GPIO_LED_7
CPU reset pushbutton (active-high)
BM29 CPU_RESET
GPIO SMA pair (applied voltage should not exceed 1.8V)
BH27 SMA_CLK_OUTPUT_P
BJ27 SMA_CLK_OUTPUT_N
Chapter 3: Board Component Descriptions
FPGA (U1)
I/O Standard
Direction
Output LVCMOS18
Output LVCMOS18
Output LVCMOS18
Output LVCMOS18
Output LVCMOS18
Output LVCMOS18
Output LVCMOS18
Output LVCMOS18
Input LVCMOS12
I/O LVCMOS18
I/O LVCMOS18
