Xilinx VCU128 User Manual page 83

Table 31: J18 VITA 57.4 FMCP HSCP Connections (cont'd)
J18
Schematic
FMCP
Net Name
HSCP
Pin
G2 FMCP_HSPC_CLK1_M2C_P
G3 FMCP_HSPC_CLK1_M2C_N
G6 FMCP_HSPC_LA00_CC_P
G7 FMCP_HSPC_LA00_CC_N
G9 FMCP_HSPC_LA03_P
G10 FMCP_HSPC_LA03_N
G12 FMCP_HSPC_LA08_P
G13 FMCP_HSPC_LA08_N
G15 FMCP_HSPC_LA12_P
G16 FMCP_HSPC_LA12_N
G18 FMCP_HSPC_LA16_P
G19 FMCP_HSPC_LA16_N
G21 FMCP_HSPC_LA20_P
G22 FMCP_HSPC_LA20_N
G24 FMCP_HSPC_LA22_P
G25 FMCP_HSPC_LA22_N
G27 FMCP_HSPC_LA25_P
G28 FMCP_HSPC_LA25_N
G30 FMCP_HSPC_LA29_P
G31 FMCP_HSPC_LA29_N
G33 FMCP_HSPC_LA31_P
G34 FMCP_HSPC_LA31_N
G36 FMCP_HSPC_LA33_P
G37 FMCP_HSPC_LA33_N
G39 VADJ_1V8_FPGA
UG1302 (v1.0) December 21, 2018
VCU128 Board User Guide
J18
FPGA
I/O FMCP
(U1)
Standard HSCP
Pin
Pin
J18 Sections G/H Connections to FPGA U1
LVDS G18 H1
LVDS G17 H2
LVDS E24 H4
LVDS E23 H5
LVDS B27 H7
LVDS A26 H8
LVDS E27 H10
LVDS D27 H11
LVDS J22 H13
LVDS H22 H14
LVDS K24 H16
LVDS K23 H17
LVDS A21 H19
LVDS A20 H20
LVDS B16 H22
LVDS A16 H23
LVDS D20 H25
LVDS D19 H26
LVDS H19 H28
LVDS H18 H29
LVDS H17 H31
LVDS G16 H32
LVDS K21 H34
LVDS J21 H35
H37
H38
H40
Chapter 3: Board Component Descriptions
Schematic Net Name
FMCP_HSPC_VREF_A_M2C
FMCP_HSPC_PRSNT_M2C_B
FMCP_HSPC_CLK0_M2C_P
FMCP_HSPC_CLK0_M2C_N
FMCP_HSPC_LA02_P
FMCP_HSPC_LA02_N
FMCP_HSPC_LA04_P
FMCP_HSPC_LA04_N
FMCP_HSPC_LA07_P
FMCP_HSPC_LA07_N
FMCP_HSPC_LA11_P
FMCP_HSPC_LA11_N
FMCP_HSPC_LA15_P
FMCP_HSPC_LA15_N
FMCP_HSPC_LA19_P
FMCP_HSPC_LA19_N
FMCP_HSPC_LA21_P
FMCP_HSPC_LA21_N
FMCP_HSPC_LA24_P
FMCP_HSPC_LA24_N
FMCP_HSPC_LA28_P
FMCP_HSPC_LA28_N
FMCP_HSPC_LA30_P
FMCP_HSPC_LA30_N
FMCP_HSPC_LA32_P
FMCP_HSPC_LA32_N
VADJ
Send Feedback
FPGA
I/O
(U1)
Standard
Pin
LVDS F24
LVDS F23
LVDS L23
LVDS K22
LVDS C25
LVDS C24
LVDS K27
LVDS J27
LVDS B26
LVDS B25
LVDS J26
LVDS J25
LVDS B18
LVDS B17
LVDS A19
LVDS A18
LVDS C18
LVDS C17
LVDS G21
LVDS F21
LVDS J20
LVDS J19
LVDS H20
LVDS G20
