• 144 Mb 36-bit dual-port QDR-IV component memory interface (1 x [4M x 36])
• 288 MB 72-bit RLD3 component memory interface (2 x [1.125 Gb x 36])
• 2 Gb Quad SPI flash configuration memory
• QSFPF28 - Sixteen (16) GTY transceivers are allocated for a 1x4 QSFP cage
• USB JTAG interface (FTDI FT4232HL with a micro-AB USB connector)
• Clock sources:
SMA I/F clocks:
○
- FPGA bank 67 SMA clock P/N
QSFP clocks:
○
- Four Si570 I2C programmable clock oscillators (156.25 MHz default)
- QSFP clock recovery Si5328 input to GTY132 and GTY134
- QSFP external SMA diff. clock input to GTY131
Memory I/F clocks:
○
- Three SiT9120A fixed 100 MHz LVDS clock oscillators
PCIe ® I/F clock:
○
- Fixed 100 MHz HCSL clock from PCI Express
to GTY225 and GTY227
System controller clock:
○
- SiT8008A 33.33 MHz single-ended clock oscillator
• 96 GTY transceivers (24 Quads)
FMCP HSPC connector (twenty-four GTY transceivers)
○
4x28 Gb/s QSFP+ connectors (eight GTY transceivers)
○
PCIe 16-lane edge connector (sixteen GTY transceivers)
○
Not used (forty-eight GTY transceivers)
○
• PCI Express ®
Gen1 (x1, x2, x4, x8, x16)
○
Gen2 (x1, x2, x4, x8, x16)
○
Gen3 (x1, x2, x4, x8, x16)
○
Dual Gen4 (x1, x2, x4, x8)
○
• Ethernet PHY SGMII interface with RJ-45 connector
• Dual USB-to-UART bridge with micro-B USB connector (shared FTDI FT4232HL)
UG1302 (v1.0) December 21, 2018
VCU128 Board User Guide
Endpoint connectivity
Chapter 1: Introduction
® edge input to 1-to-2 clock buffer wired
