Xilinx VCU128 User Manual page 25

1.2V 168-ball BGA
○
Up to RL3-1866
○
The VCU128 XCVU37P FPGA RLDRAM3 interface performance is documented in the Virtex
UltraScale+ FPGA Data Sheet: DC and AC Switching Characteristics (DS923).
This memory system is connected to the XCVU37P HP banks 73, 74, and 75. The RLD3 0.6V
VTT termination voltage (net RLD3_VTERM_0V6) is sourced from TI TPS51200DR linear
regulator U92. The RLD3 memory interface bank VREF pins are not connected, which, coupled
with an XDC set_property INTERNAL_VREF constraint, invoke the INTERNAL VREF mode. The
connections between the RLD3 component memories and XCVU37P banks 73, 74, and 75 are
listed in the following table.
