Connecting to Syrup Supply - Figal Syrup Tank
1. Connect tubing routed from CO
syrup tank CO inlet.
2
B
2. Using tubing cutters, cut line from CO
tank and install tee fitting, then route appropriate tubing
from second figal syrup CO
E
B
3. Repeat step 2 for remaining figal syrup tanks.
4. Cut tubing from dispenser CO
syrup tanks and install another tee fitting.
12
inlet in dispenser to figal
2
A
C
A. Figal Connector
B. Line From CO Inlet
2
C. Oetiker Pliers
inlet to figal syrup
2
inlet to tee fitting.
2
D
C
A
A. Tee Fitting
B. Line to Dispenser
C. Line to First Figal Tank
D. Line to Second Figal Tank
E. Fitting
inlet to tee fitting at figal
2
5. Route appropriate tubing from CO
between dispenser CO
connect tubing to tee fitting.
D
A
B
6. Connect tubing from dispenser syrup inlet to the figal syrup
outlet fitting. Repeat for each syrup line/tank.
supply to tee fitting
2
inlet and figal syrup tanks and
2
A. Tee Fitting
B. Line to Tee at Figal Tank
C. Dispenser CO Inlet
2
D. CO Supply
2
C
A
B
A. Figal Connector
B. Figal Container
C. Syrup Line
C
