INSTALLATION AND SERVICE MANUAL
CENTURION II JUICE DISPENSER
This manual was reissued by Lancer in June 1997
"Lancer" is the registered trademark of Lancer
• NORTH AMERICA – 210-310-7245 • INTERNATIONAL SALES – 210-310-7242 • CUSTOMER SERVICE – 210-310-7242 •
• LATIN AMERICA – 210-310-7245 • EUROPE – 32-2-755-2399 • PACIFIC – 61-8-8268-1978 •
"Lancer" is the registered trademark of Lancer
FOR
Part Number 85-0055, 115 Volts, 60 Hz
Part Number 85-0056, 230 Volts, 50 Hz
6655 LANCER BLVD. • SAN ANTONIO, TEXAS 78219 USA • (210) 310-7000
FAX SALES
FAX ENGINEERING: • 210-310-7096
Please refer to the Lancer web site (www.lancercorp.com) for
information relating to Lancer Installation and Service Manuals,
Instruction Sheets, Technical Bulletins, Service Bulletins, etc.
•
Copyright — 1997 by Lancer, all rights reserved.
•
Copyright — 1992 by Lancer, all rights reserved.
DATE:
07/31/92
P.N.
28–0019
