Ice Cooled Drop-In
Series: 2200, 2300, 23300
Operation Manual
ICDI 2300 8-Valve
ICDI 2200 6-Valve
ICDI 23300 8-Valve
Lancer
is a registered trademark of Lancer Corp.
®
For more Information visit
lancerworldwide.com
or call Tech Support/Warranty: 800-729-1550
6655 Lancer Boulevard • San Antonio, TX 78219 • custserv@lancerworldwide.com • ©2018,2020,2022 Lancer Corp. • Lancer PN: 28-3007 • Revision 00-4, 06/8/23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 23300 Series and is the answer not in the manual?

Questions and answers

Related Manuals for lancer 23300 Series

Summary of Contents for lancer 23300 Series

  • Page 1 Lancer Corp. ® For more Information visit lancerworldwide.com or call Tech Support/Warranty: 800-729-1550 6655 Lancer Boulevard • San Antonio, TX 78219 • custserv@lancerworldwide.com • ©2018,2020,2022 Lancer Corp. • Lancer PN: 28-3007 • Revision 00-4, 06/8/23...

  • Page 2: Table Of Contents

    DISPENSER DISPOSAL............22 ICDI 23300 ................7 ILLUSTRATIONS AND PART LISTINGS......23-34 General Systems Overview - Remote Syrup Pumps..8-9 Pre-Installation Checklist............9 Lancer Ice Cooled Dispenser - Accessories......23 Series 2200 Drop-In.............24 INSTALLATION..............10-16 Series 2300 Standard Performance Drop-In......25 Unpacking the Dispenser.............10 Series 2300 High Performance Drop-In......26-27 Selecting/Preparing a Counter Location......10...

  • Page 3: Intended Use

    ! Intended Use The dispenser is for indoor use only. This unit is not a toy. Children should be supervised not to play with appliance. It should not be used by children or infirm persons without supervision. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

  • Page 4: Specifications And Features

    SPECIFICATIONS AND FEATURES ICDI 2200 18.125” (460 mm) Above Counter 34.25” (870 mm) 16.125” (410 mm) Below Counter A. Valves 23” B. Splash Plate (584 mm) C. Cup Rest D. Drip Tray 15” (381 mm) E. Sliding Bin Cover F. Ice Bin G.

  • Page 5: Icdi 2300 Standard Performance

    ICDI 2300 Standard Performance 23” (584 mm) 18.1” (459 mm) 19.3” (491 mm) 42.4” 25.2” (1077 mm) 25.2” (640 mm) (640 mm) 23.1” (586 mm) 23” 23” (584 mm) (584 mm) A. Ice Bin B. Sliding Bin Cover C. Drip Tray D.

  • Page 6: Icdi 2300 High Performance

    ICDI 2300 High Performance 6 & 8 valves 10 valves 23” (584 mm) 27.5” (699 mm) 18.1” (459 mm) 19.3” (491 mm) 42.4” 25.2” (1077 mm) 25.2” (640 mm) (640 mm) 23.1” (586 mm) A. Ice Bin B. Sliding Bin Cover 23”...

  • Page 7: Icdi 23300

    ICDI 23300 30” (762 mm) 18” (457 mm) 19.3” (490 mm) 22.1” (562 mm) 18” 32” 25” (457 mm) (813 mm) (635 mm) 41.5” (1055 mm) A. Valves B. Splash Plate C. Cup Rest 23” D. Drip Tray 30” (584 mm) E.

  • Page 8: General Systems Overview - Remote Syrup Pumps

    2200 & 23300 General System Overview - Remote Syrup Pumps Syrup Line Line Plain Water Line Carb Water Line Drain Line Electrical A. Water Source B. Water Booster C. Floor Drain D. Water Regulator E. Remote Carbonator F. Syrup Pump G.

  • Page 9: Pre-Installation Checklist

    BIB Rack Can the countertop support the Water Booster weight of the dispenser (include BIB Syrup Boxes (Lancer PN: MC-163172) the weight of an ice machine plus weight of ice, if necessary)? BIB Regulator Set Water Regulator Is dispenser located away from...

  • Page 10: Installation

    Read This Manual This manual was developed by Lancer Worldwide as a reference guide for the owner/operator and installer of this dispenser. Please read this manual before installation and operation of this dispenser. Please see Troubleshooting section for service assistance. If the service cannot be corrected please call your Service Agent or Lancer Customer Service.

  • Page 11: Dispenser Installation - 2200 & 23300

    12. Install BIB connectors to the syrup supply line tubing. the counter, including the shipping risers, which Lancer recommends be left attached to the unit. Should the dispenser ever require removal, the shipping risers will protect the inlet tubes from being damaged.
  • Page 12 16. Install drain lines to both front and back drain fittings then 13. Attach BIB connectors on syrup supply line to BIB. Repeat for each syrup line/pump. tee the two drain lines together at the back of the unit. ! ATTENTION Use proper connector for syrup manufacturer.

  • Page 13: Dispenser Installation - 2300

    Install water regulator and filter to water line and, if riser legs in the back of the unit. necessary, install water booster (Lancer PN MC-163172) between water supply and the unit. Using tubing cutters, cut soda water line and install remote carbonator per manufacturer’s specifications (see General...
  • Page 14 11. Connect each syrup line to appropriate syrup inlet in the 15. Install threaded drain fitting (PN: 01-1612), included in front of the unit (see Plumbing Diagrams on the front of the accessory kit, to front drain line. unit or on pages 29-32 for reference). ! ATTENTION If installing a 6-Valve unit, two of the syrup lines will be capped.

  • Page 15: Installing Co Supply

    Installing CO Supply Connect high pressure CO regulator assembly to CO Turn the knob on the CO regulator, at the source, all the cylinder or bulk system. way to the left (counterclockwise) to close the regulator. Repeat for CO regulator at the syrup pumps. ! ATTENTION Before installing regulator, ensure that a seal (washer A.

  • Page 16: Dispenser Setup

    Dispenser Setup Turn on water source. Turn on CO at the source then turn the knob on the CO regulator at source to the right (clockwise) until regulator Place enough ice in the ice bin to fill approximately 1/2 of reads 105 psi (0.724 MPa).

  • Page 17: Adjust Syrup/Water Ratio

    11. Remove the Valve ID Panel for the first valve. 12. Use a Lancer ratio cup to verify water flow rate (5 oz. in 4 sec.). Use a screwdriver to adjust if needed. Increase Decrease A. Flow Control, Water A. Valve ID Panel B.

  • Page 18: Cleaning And Sanitizing

    General Information GENERAL INFORMATION Lancer equipment is shipped from the factory after being cleaned and sanitized in accordance with the National Sani- tation Foundation (NSF) guidelines. The operator of the equipment must provide continuous maintenance as required by this manual and/or state and local health department guidelines to ensure proper operation and sanitation require- ments are maintained.

  • Page 19: Cleaning And Sanitizing Nozzles

    Cleaning and Sanitizing Nozzles Prepare the cleaning and sanitizing solutions as described in Remove diffuser by pulling down. “Cleaning and Sanitizing Solutions” section. Rinse nozzle and diffuser with warm water. Disconnect power, so as to not activate valve while clean- Wash nozzle and diffuser with cleaning solution then ing.

  • Page 20: Troubleshooting

    TROUBLESHOOTING Dispenser Troubleshooting TROUBLE CAUSE REMEDY No product when valve Keyswitch is off or keyswitch harness is Turn keyswitch on and/or reconnect keyswitch is activated. disconnected. harness. No power to dispenser. Check internal breaker and incoming power. Malfunctioning switch assembly. Replace switch assembly.
  • Page 21 TROUBLE CAUSE REMEDY Low or no carbonation. Low or no CO Check CO supply. Adjust CO pressure to 90 PSI - 110 PSI (0.621 MPA - 0.758 MPA). Low water pressure. Need water booster kit. Worn or defective carbonator pump. Replace carbonator pump.

  • Page 22: Remote Syrup Pump Troubleshooting

    TROUBLE CAUSE REMEDY Water in ice bin. Cold plate drain is obstructed. Remove obstruction from drain wire. Noisy/cavitating carbon- Insufficient incoming water supply pressure. Verify incoming supply water pressure to ator pump. carbonator pump is 40 PSI (0.276 MPA) and Loose pump coupling.

  • Page 23: Illustrations And Part Listings

    ILLUSTRATIONS AND PART LISTINGS Lancer Ice Cooled Dispenser - Accessories Illuminated Merchandiser PN 85-2304 Illuminated Marquee PN 85-2301 for 2200 PN 85-2302 for 2300 PN 85-2303 for 23300 Splash Guards Kit PN 82-2479 for 2200 PN 82-2076 for 2300 PN 82-2077 for 23300...

  • Page 24: Series 2200 Drop-In

    Series 2200 Drop-In Item Part No. Description 30-5617 Tower Cap 12-0097 Switch, Key Lock 82-2112 Switch/Bracket Assembly 23-0862 Wire Drain Assembly 30-11742 05-1512/01 Drip Tray 23-1214 Cup Rest 30-7093 Splash Plate 30-11907 Ice Bin Cover 19-0397 /03 LEV without mounting block 19-0434/03 LEV Self Serve Lever without mounting block...

  • Page 25: Series 2300 Standard Performance Drop-In

    Double Sliding Bin Lid, Cut Off 12-0097 Key Lock Switch, Maintain, Spade 82-3029 Power Supply Assembly, 120-24 30-5424-01 Splash Plate, 23” w/ Lancer Logo V, 75 W, EX SW 07-0405 Hole Plug, 3/4” Dia, SS 07-0437 Oetiker Clamp, 7/16” 23-0862...

  • Page 26: Series 2300 High Performance Drop-In

    Series 2300 High Performance Drop-In...
  • Page 27 Left Tower Structure Assy, 6V 12-0097 Key Lock Switch, Maintain, Spade 82-6363 Center Tower Structure Assy, 6V 30-5424 Splash Plate, 23” w/o Lancer Logo 82-6364 Right Tower Structure Assy, 6V 07-0405 Hole Plug, 3/4” Dia, SS 82-6145/01 Left Tower Structure Assy, 8V...

  • Page 28: Series 23300 Drop-In

    Series 23300 Drop-In Item Part No. Description 30-12702 Tower Cap 12-0097 Key Lock Switch 82-2118 Bin Lid Switch kit 30-6041/03 Sliding Lid 05-1092 Drip Tray 23-1001/01 Cup Rest 30-5926/01 Splash Plate 51-6119/01 Ice Bin Cover 19-0397 /03 LEV without mounting block 19-0434/03 LEV Self Serve Lever without mounting block...

  • Page 29: Plumbing Diagrams

    Plumbing Diagrams 2200, Standard Performance, 5 Valve & 6 Valve, (3-1-2) & (2-1-2) 2200, Standard Performance, 6 Valve, (3-2-1)
  • Page 30 2300, 6 Valve, Standard Performance 2300, 8 Valve, Standard Performance 2300, 10 Valve, Standard Performance...
  • Page 31 2300, 6 Valve, High Performance Plumbing Diagram 2300, 8 Valve, High Performance Plumbing Diagram 2300, 10 Valve, High Performance Plumbing Diagram...

  • Page 32: Tower Plumbing Diagrams

    Tower Plumbing Diagrams 2300, Standard Performance 6 Valve 2300, Standard Performance 8 Valve 2300, Standard Performance 10 Valve...

  • Page 33: Wiring Diagrams

    Wiring Diagrams ICE COOLED UNIVERSAL Ice Cooled Universal Wiring Diagram with Bin Lid Switch WIRING DIAGRAM WITH BIN LID SWITCH WATER SPIGOT BUTTON SYRUP OUT LIGHT KIT REPLACES INTERNAL CHERRY SWITCH HARNESS PRESSURE SWITCH ON SPRITE VALVE SOLENOID BLACK BLACK WHITE BLACK WHITE...

  • Page 34: Counter Cutout Diagrams

    Counter Cutout Diagrams 2200 Cutout 23 1/4" (591 mm) 17" 15 1/4" FRONT (432 mm) (387 mm) 25" (635 mm) SIDE (View Looking Down) 2323 Cutout 23 1/4" (591 mm) 25.5" 23 1/4" (648 mm) (591 mm) 25.25" (641 mm) 3023 Cutout 30 1/4"...
