INSTALLATION AND SERVICE MANUAL
LANCER SERIES 4500
PART NO.
85-4528H
85-4538H
85-4425H
85-4435H
DIMENSIONS
HEIGHT:
WIDTH:
DEPTH:
TOTAL ICE CAPACITY:
DISPENSABLE ICE CAPACITY:
COUNTER WEIGHT (WITHOUT ICE):
SHIPPING WEIGHT:
ELECTRICAL
VOLTAGE:
AMPS:
Hz:
THIS UNIT IS EQUIPPED WITH AUTOMATIC AGITATION.
DO NOT PLACE HANDS, OR FOREIGN OBJECTS IN THE ICE STORAGE COMPARTMENT.
WHEN UNIT IS BEING SERVICED, CLEANED, OR SANITIZED, UNPLUG DISPENSER FROM THE
POWER SOURCE.
Lancer does not recommend the use of shaved, flake, nugget, or pellet ice in the dispenser.
Dispenser will only operate with cube ice.
This manual supersedes Installation and Service Manual 28-0417/01, Dated 03/10/04,
and is being published on the Lancer Web Site only.
• NORTH AMERICA – 210-310-7245 • INTERNATIONAL SALES – 210-310-7242 • CUSTOMER SERVICE – 210-310-7242 •
• LATIN AMERICA – 210-310-7245 • EUROPE – 32-2-755-2399 • PACIFIC – 61-8-8268-1978 •
IBD25
DESCRIPTION
ICE BEVERAGE DISPENSER, 25 INCH WIDE, 8V, 115V/60Hz
ICE BEVERAGE DISPENSER, 25 INCH WIDE, 8V, 230V/50-60Hz
ICE DISPENSER,
ICE DISPENSER,
SPECIFICATIONS
34.0 Inches
25.0 Inches
30.5 Inches
210 Pounds (95.45 kg)
170 Pounds (77.27 kg)
250 Pounds (113.64 kg)
285 Pounds (129.55 kg)
115
3.6
60
6655 LANCER BLVD. • SAN ANTONIO, TEXAS 78219 USA • (210) 310-7000
• FAX ENGINEERING: • 210-310-7096 •
• "Lancer" is the registered trademark of Lancer •
• Copyright — 2006 by Lancer, all rights reserved. •
Please refer to the Lancer web site (www.lancercorp.com) for
information relating to Lancer Installation and Service Manuals,
Instruction Sheets, Technical Bulletins, Service Bulletins, etc.
25 INCH WIDE, 115V/60Hz
25 INCH WIDE, 230V/50-60Hz
(864 mm)
(635 mm)
(775 mm)
230
1.8
50/60
WARNING
IT MAY ACTIVATE UNEXPECTEDLY.
NOTE
FAX SALES
DATE:
02/15/06
P.N.
28–0417/02
