Appendix A - Technical Specifications
Appendix A
ISO 7810 and ISO 7811, AAMVA
TDEA (3DES)-CBC using DUKPT
PCI PTS v4.x
EMV ICC Specifications for Payment Systems Version 4.3
EMV Contactless Level 1 Book D v2.5
PayPass v3.0.2
payWave v2.1.3b
Expresspay v3.0
Discover v1.1
FCC Title 47 Part 15 Subclass C EMC
CE Level B EMC
CE Safety
AS/NZS 4268:2017
UR/CUR UL Recognized
MasterCard TQM
California Proposition 65 (California)
WEEE (EU)
IEEE 802.11 b/g/n, IEEE 802.11i-2004
WPA2-PSK, TKIP, AES, SHA-256
TCP/IP secured by Transport Layer Security (TLS) Protocol v1.2
USB 1.1, USB 2.0
Dimensions (L x W x H):
Weight (802.11, No SigCap):
Display Type:
Display Size (viewable area):
Display Resolution:
Keypad:
Card Reader (magnetic stripe):
Card Reader (chip card):
Contactless Reader:
Acceptable Swipe Speeds:
DynaPro Go| Handheld PIN Pad Device with MSR/Contact/Contactless | Installation and Operation Manual
Technical Specifications
DynaPro Go Technical Specifications
Reference Standards and Certifications
Physical Characteristics
6.1 in. (155 mm) x 2.8 in. (71 mm) x 1.0 in. (25.4 mm)
8.85 oz. (251 g)
User Interface Characteristics
QVGA TFT LCD Color
1.97 in. (49.96mm) x 1.48 in. (37.72mm)
320x240 pixels
16-bit color depth
Full-travel membrane keypad providing tactile feedback
10 digits, 2 data entry keys, 3 multi-purpose function keys
Triple Track (TK1/2/3), encrypting reader with MagnePrint
EMV chip card reader
EMV contactless reader
10 inches per second to 50 inches per second
Page 58 of 60 (D998200129-10)
