6 - Operation
6.3

Power Management

6.3.1 How to Charge the Battery

DynaPro Go's Lithium Polymer (LiPo) rechargeable battery will deliver best
performance when it is completely or almost completely drained and then receives a full
charge, as opposed to other rechargeable battery types that require constant
"topping-off" recharging. Using the device until the battery is low will enhance the
device's performance and provide a better user experience.
DynaPro Go has an onboard rechargeable battery to supply its own power when it is not powered through
its USB port. The battery must be periodically recharged by connecting it to the available charging
cradle, or to a USB port or stand-alone USB charger. Both the charging cradle and the device require a
USB power supply that can provide at least 500mA @ 5V.
To charge the device using a micro-USB cable, connect it to a USB charger, or to a USB host as shown in
section 4.3.1 How to Connect DynaPro Go to a Computer Host or Charger via USB on page 20.
To charge the device in the charging cradle for power only (no USB communication):
1) Connect the charging cradle to a USB port or to a USB charger.
2) Place the device in the charging cradle with the charging contacts pointing into the charging cradle
and the LCD display facing front.
A full recharge cycle for a completely drained battery takes approximately 6 hours.
DynaPro Go| Handheld PIN Pad Device with MSR/Contact/Contactless | Installation and Operation Manual
Note
Figure 6-9 - Device In Charging Cradle
Page 42 of 60 (D998200129-10)
