5 - Configuration
5.2

How to Configure the Keypad Backlight

The device's keypad has a backlight that can be configured to either remain at a constant brightness level
(Default mode) or adapt its brightness to ambient lighting based on the device's light sensor (Auto
mode). The factory default of the device is
To change the keypad backlight mode, press
the
LED Brightness Config
The
LED Brightness Config
the mode, press the function key below the selection you want, then press the
change. To exit without saving changes, press the
to the screen.
Welcome
When the device is in
Auto
on ambient light detected by the light sensor (see section 2.10 Major Components). The brightness
levels the device will select are shown in Table 5-3. When the device is in
keeps the keypad backlight brightness at
Table 5-3 - Keypad Backlight Brightness Levels
Light Level Keypad Brightness Level
High Off (0%)
Medium Medium (33%)
Low High (67%)
Very Low Maximum (100%)
DynaPro Go| Handheld PIN Pad Device with MSR/Contact/Contactless | Installation and Operation Manual
Default
Left Function Key 5 3 3 Right Function Key
screen.
screen shows the mode the keypad backlight is currently using. To change
Cancel
mode, the device adjusts the keypad backlight brightness automatically based
.
Maximum
Page 25 of 60 (D998200129-10)
mode, which uses
Maximum
key or wait 10 seconds for the device to return
Default
brightness.
to open
key to save the
Enter
mode, the device
