6 - Operation
6.2

How to Read Device Status

6.2.1 Welcome Screen Status Icons

The device reports its current status in a set of icons at the top of the
the icons and their meanings. For example, in Figure 6-3, the device is connected to a USB host, the
battery level is OK, the device is charging, and it is idle, waiting for the host to initiate a transaction.
Table 6-1 - Status Icon Meanings
Status Icon
A green rectangle appears briefly at the upper left corner of the display every 5
seconds to indicate the device is Idle; the device is connected to a host and is ready
for the host to initiate a transaction.
During tap-enabled transactions, the device uses a strip of four green rectangles at
the top of the screen to indicate the progress / success of a tap. See section 6.5.3
How to Tap Contactless Cards / Devices for details.
Device's Active Connection is set to USB, and the device has successfully
established a USB communication connection with the host.
Device's Active Connection is set to 802.11 wireless, the device is connected to a
wireless access point, and the device is communicating with the host. The number
Solid
of bars indicates the strength of the signal the device is receiving from the wireless
access point (commonly known as RSSI).
Device's Active Connection is set to 802.11 wireless, the device is connected to a
wireless access point, but the device can not connect to the host. The number of
Blinking
bars indicates the strength of the signal the device is receiving from the wireless
access point (commonly known as RSSI).
Device is not connected to a host via any connection type.
Battery is fully charged.
Battery is OK, between 20% and 95% charged.
Battery is low, between 10% and 20% charged.
Battery is critically low, between 3% and 10% charged.
Battery is empty, below 3% charged.
Battery is charging.
<No indicator> Battery is not charging.
