Hardware layout and configuration

6 Hardware layout and configuration
The STM32 Nucleo-32 board is based on a 32-pin STM32 microcontroller in LQFP or
UFQFPN package.
Figure 2
push-button, LED, and Arduino Nano connectors).
Figure 3: STM32 Nucleo-32 board top layout
layout show the location of these connections on the STM32 Nucleo-32 board.
10/37
illustrates the connections between the STM32 and its peripherals (ST-LINK/V2-1,

Figure 2. Hardware block diagram

and Figure 4: STM32 Nucleo-32 board bottom
