Hardware layout and configuration
CN4
Arduino Nano connector
SB18
Connect D4 to A4
SB16
Connect D5 to A5
SB11
Connect
GND
SB14
3.3V regulator output
SB15
Connect D13 to LD3
12/37
Figure 4.
STM32 Nucleo-32 board bottom layout
pin 16 to
UM1956 Rev 5
UM1956
SB9
ST-LINK RESET
CN3
Arduino Nano connector
SB12
Connect BOOT0 to GND
SB13
Connect GND to
pin
32
SB10
Connect VDD to
pin 5
SB17
Connect MCO to PA0
JP1
IDD measurement
