Step 2 Set parameters and refer to
Step 3
Sensor
Device Type
Reboot Date
Version Info
Dial Rule
Step 4 Table 7-7 for details.
Parameter
Sensor
Device Type
Reboot Date
Version Info
Dial Rule
Click "OK" to save the settings.
Step 5

7.7.2 Facade Layout

Camera module exists by default; all other modules shall be added in facade layout before use.
At most 9 modules can be added.

Regarding fingerprint module, card swiping module and keyboard module, only one

module of each type can be added respectively. Other modules can be matched freely.
7.7.2.1 Add Modules
Select "System Config>Local Config>Faç ade Layout".
Step 1
The system displays "Façade Layout" interface, as shown in Figure 7-28.
Figure 7-27
Parameter Description
If it is dark during video intercom, turn on the fill-in
light automatically. The larger the value is, the
higher sensitivity becomes.
It is villa station by default.
Set auto reboot time of VTO. It is 2 a.m. on
Tuesday by default.
Display software version number.
Set the user's dial rule, including "Non-serial" and
"Serial".
Description
If it is dark during video intercom, turn on the fill-in light automatically.
The larger the value is, the higher sensitivity becomes.
It is villa station by default.
Set auto reboot time of VTO. It is 2 a.m. on Tuesday by default.
Display software version number.
Set the user's dial rule, including "Non-serial" and "Serial".
Table 7-7
