Ftp Server; Port - Dahua Modular VTO User Manual

Enter the planned "IP Address", "Subnet Mask" and "Default Gateway".
Step 2
Step 3 Turn on SSH according to needs.
After SSH is on, Telnet and other debugging terminals can connect VTO, operate and
debug it.
Click "OK" to save the settings.
Step 4

7.5.2 FTP Server

Set FTP server, so recordings and snapshots will be saved in FTP server.
Select "System Config > Network Config > FTP".
Step 1
The system displays ""FTP" interface, as shown in Figure 7-15.
Set the parameters and refer to 错误!未找到引用源。 for details.
Step 2
Parameter
IP Address
Port No.
Username
Password
Click "OK" to save the settings.
Step 3

7.5.3 Port

Set the port to visit WEB interface of VTO.
Select "System Config > Network Config > Port".
Step 1
The system displays "Port" interface, as shown in Figure 7-16.
Figure 7-14
Figure 7-15
Description
IP address of the host to install FTP server.
It is 21 by default.
Username and password to visit FTP server.
Table 7-1
56
