FEBRUARY 2017 Quick Install Guide VIDEO DOOR ENTRY Official UK distribution partner tel: +44 (0)1457 874 999 | fax: +44 (0)1457 829 201 | email: sales@cop-eu.com | web: www.cop-eu.com...
Page 2
The VTNS1060A is a 24v passive PoE unit, this is a different type of PoE than that seen on conventional IP devices. As such, both the VTO2000A and VTH1550CH can only be used with 24v passive PoE or by connecting a 12/24vdc power supply to the power input terminals on the units.
Page 3
VTO Camera Configuration With a PC or Laptop connected to the network switch, run the Dahua config tool to find the VTO unit. By default the VTO has an IP address of 192.168.1.110, this can be changed if required via the config tool or within the VTO web browser.
Page 4
VTH Configuration (Continued) In the project settings menu select NetSet to configure the VTH network settings. When configuring the network address of the VTH it is vital to ensure the IP address range is within the same Subnet as the VTO. For both the VTO and VTH to communicate, each unit must have the IP address details of the other unit.
Page 5
Adding Additional VTH Units When additional VTH units are to be added to the system, usually it is required that all VTH units are called by the VTO. To enable this feature and configure the additional VTH units; Login to the VTO web browser and go to System Config > LAN Config and tick the Group Call option. Click OK then select Logout >...
Page 6
Application Set Up When configured as a home system, both the VTO2000A & VTO2221D-WP support P2P connections. Currently P2P is only supported for iOS and Android devices. Download the mobile application to your mobile device by scanning the QR codes below or by searching for the app in your relative app store.
Page 7
VTO Module Configuration With a PC or Laptop connected to the network switch, run the Dahua config tool to find the VTO unit. By default the VTO has an IP address of 192.168.1.110, this can be changed if required via the config tool or within the VTO web browser.
Page 8
Module Configuration To configure the layout of the modular system, go to System Config > Local Config > Fascade Layout Click the Plus symbol in the location of the next module, then select the module type. Multiple modules can be aded to the layout. Click Save to confirm the settings, then select the Logout option on the left menu and click Reboot Device, this will restart the VTO.
Page 9
VTH Monitor Configuration To configure the VTH unit use the built in menu within the monitor itself, VTH units do not support web browser configuration. Select Settings and input the engineer password: 002236 (default) The Product Info menu is used to set the room number of the VTH and to configure the unit as a Master or Extension unit. When configuring a modular system, each monitor will be configured as a Master.
Page 10
VTH Monitor Configuration For both the VTO and VTH to communicate, each unit must have the IP address details of the other unit. To add the VTO unit to the VTH, select Network and input the VTO units IP address and set Enable Status to ON. To add the VTH to the VTO, revisit the VTO web browser and go to System Config >...
Page 11
Keypad Configuration When using the keypad module, first add it to the layout as described on page 8. The keypad module has two primary functions, calling and password entry. To make a call to a specific room, simply enter the room number followed by the phone button. To configure password entry;...
