DH-HWS200+ Radar Speed Measuring System
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DH-HWS200+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dahua DH-HWS200+

Summary of Contents for Dahua DH-HWS200+

  • Page 1 DH-HWS200+ Radar Speed Measuring System User’s Manual...
  • Page 2 Welcome Thank you for purchasing our product! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference! Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. We are not liable for any problems caused by unauthorized modification or attempted repair. 2．Installation This series product shall be installed one or three meters away from the lane.

  • Page 4: Table Of Contents

    Table of Contents General Introduction ........................6 Overview ..........................6 Functions ..........................6 Features..........................7 Specifications ........................8 Chinese National and Industry Criteria ................ 9 Structure ............................10 Appearance........................10 Panel and Ports ......................11 2.2.1 Right Panel ....................... 11 2.2.2 Front Panel .......................
  • Page 5 4.1.3 Input Method ......................17 Menu Operation ......................17 4.2.1 Main Interface ......................17 4.2.2 Snapshot ........................18 4.2.3 Road Monitor ......................19 4.2.4 System Setting ......................20 4.2.5 Image Search ......................27 4.2.6 Image Backup ......................29 4.2.7 System Information ....................33 FAQ ..............................

  • Page 6: General Introduction

    The built-in design is stable and of strong function. It is easy to use and very convenient to install. It can be widely used in many areas. This series product also integrated the Dahua’s technical advantages in the security area. It is a perfect product integrating the security area and the intelligent transportation system together.

  • Page 7: Features

    The DH-HWS200+ series product adopts the Dahua’s technical advantages in the security area. The host software circuit adopts the mature platform Dahua has already used in the security area. The hardware circuit is also be optimized and perfected to use in the industry-level or military level chips, which lowers the system power consumption and can guarantee the long time running period in the harsh environments.

  • Page 8: Specifications

    There is a 2 mega high definition CCD camera to snapshoot the offence vehicle. System can overlay information such as the vehicle speed, snapshot time, snapshot position. The built-in watermark function prevents the vicious image modification, which maximally guarantees the authentic image.

  • Page 9: Chinese National And Industry Criteria

    Spec Working distance：>60m Oscillation frequency：34.7GHz Transmission power：≤10mW Antenna beam width：horizontal 5 degrees (-3dB), vertical 15degrees (-3dB) Reactive time：≤0.1s Power voltage：DC 10.5~14.5V Power consumption：The current is lower than 700mA when it is the 12V rated voltage. Working temperature：（-30~70）℃ Enclosure：High density industrial plastic 1.5 Chinese National and Industry Criteria ...

  • Page 10: Structure

    2 Structure 2.1 Appearance This series product appearance is shown as below. See Figure 2-1 and Figure 2-2. DH-HWS200+ Radar speed measuring system mainly consists of the power, embedded snapshot module, flash light, radar and LCD. The embedded snapshot module is the key unit of the whole system which is in charge of the image snapshot, flash light synchronization, camera control, radar speed setup, getting the speed, disk storage, network transmission, USB download and GUI display.

  • Page 11: Panel And Ports

    Figure 2-2 2.2 Panel and Ports 2.2.1 Right Panel Please refer to the following figure for right panel information. See Figure 2-3.

  • Page 12: Front Panel

    Figure 2-3 Please refer to the following sheet for detailed information. Port Name Camera port Power button Flash light and DC19V power input port. 2.2.2 Front Panel The front panel is shown as in Figure 2-4.

  • Page 13: Left Panel

    Figure 2-4 Please refer to the following sheet for detailed information. Icon Description Color Function Flashing: System is working properly. System running On: System has stopped Green indication light working. Off: system has stopped working. Flashing: Lithium battery is Lithium battery recharging now,.

  • Page 14: Remote Control

    Figure 2-5 Please refer to the following sheet for detailed information. Port Name Lithium battery Network, USB port, DC 12V power output and etc. 2.3 Remote Control The remote control is shown as below. See Figure 2-6 Please note the remote control is an optional accessory and it is not included in the accessory bag.
  • Page 15 Please refer to the following sheet for detailed information. Name Function It is the on/off button to shut down/boot up the LCD power or switch between the working/standby modes. Press the POWER button once; you can close the LCD POWER power.

  • Page 16: Installation

    3 Installation 3.1 Device Installation Take the device out of the box. Insert the Lithium battery. Put the device on the tripod and adjust to the proper height. Push the power button to boot up the device. 3.2 Camera Debug Go to the Road Monitor interface.

  • Page 17: Operation

    4 Operation Important  Before your operation, please make sure all cable connections are right and the Lithium battery has inserted in the slot.  Please make sure you have removed the USB device before you boot up the device! ...

  • Page 18: Snapshot

    Figure 4-1 4.2.2 Snapshot Please highlight the Snapshot item and then click; you can see the following interface. Here you can see the vehicle snapshot image and view its detailed information. See Figure 4-2.  Date: The image snapshot date. ...

  • Page 19: Road Monitor

    Figure 4-2 4.2.3 Road Monitor The road monitor interface is shown as below. Here you can view vehicle real-time running status. When you are debugging the system, you can go to the following figure to view the camera effect. See Figure 4-3. ...

  • Page 20: System Setting

    Figure 4-3 4.2.4 System Setting 4.2.4.1 Radar Setting The radar setting interface is shown as in Figure 4-4.  Min speed limit: Here you can use the left/right button to highlight the enable/disable min speed measurement and snapshot function.  Min speed limit value: Here you can input the min speed limit value.
  • Page 21 Figure 4-4 4.2.4.2 Camera Setting The camera setting interface is shown as below. See Figure 4-5.  Exposure time: It includes seven options: 250ms/500ms/1ms/2ms/4ms/8ms/20ms. The default value is 1ms.  Flash mode: There are two modes: always flash and auto flash.
  • Page 22 Figure 4-5 4.2.4.3 Location Setting The location setting interface is shown as in Figure 4-6.  Road direction: Use the up/down button in the remote control to select the road direction from the dropdown list. It includes five options: No direction (default)/from the north to the south/from the south to the north/from the east to the west/from the west to the east.
  • Page 23 Figure 4-6 4.2.4.4 Network Setting The network setting interface is shown as in Figure 4-7.  Host IP: Here you can set host IP address.  Subnet mask: Here you can set host subnet mask.  Gateway: Here you can set host gateway. ...
  • Page 24 Figure 4-7 4.2.4.5 Server Setting The server setting interface is shown as in Figure 4-8.  Server function: You can highlight the enable/disable item to use or not to use this function.  Connection mode: It includes two options: IP address or domain name. You can highlight the corresponding option to select.
  • Page 25 Figure 4-8 4.2.4.6 NTP Setting The NTP setting interface is shown as below. See Figure 4-9.  NTP: It includes two options: enable/disable.  Connection mode: It includes two options: IP address/domain name.  Time server: Here you can input NTP server IP address. ...
  • Page 26 Figure 4-9 4.2.4.7 FTP Setting FTP setting interface is shown as in Figure 4-10.  Function: It includes two options: enable/disable.  Connection mode: It includes two options: IP address/domain name.  FTP server: Here you can input FTP server IP address. ...

  • Page 27: Image Search

    Figure 4-10 Image Search 4.2.5 The image search interface is shown as in Figure 4-11. Please select the corresponding start time and end time first, and then you can click the Start button to begin the search.
  • Page 28 Figure 4-11 After completed the search, you can see the following interface. See Figure 4-12. On the left pane, you can see the image SN, snapshot time and speed. The image thumbnail, snapshot date, time and speed limit information are on the right pane. System displays the first image by default.

  • Page 29: Image Backup

    After you selected one record and then click the OK button in the remote control (or you can click the image thumbnail on the right pane), you can go to the image view interface. See Figure 4-13. You can view the detailed image on the left pane and its corresponding information is on the right pane.
  • Page 30 Figure 4-14 During the backup process, you can view a backup process bar at the bottom of the interface. See Figure 4-15. You can click the Cancel button to terminate current operation. During the backup process, you can switch to other interface to operate. The backup operation is...
  • Page 31 running in the background. Figure 4-15 When the backup completed (the percentage reaches 100%), you can see the system pops up the following dialogue box. See Figure 4-16. Please remove the backup device and click the OK button to go to the backup interface. Figure 4-16...
  • Page 32 If there is no USB device available, system may pop up the following dialogue box. See Figure 4-17. Please click the OK button to try again or you can click the Cancel button to go to the backup interface. Figure 4-17 During the backup process, if the USB device capacity is full, system may pop up the following dialogue box.

  • Page 33: System Information

    Figure 4-18 4.2.7 System Information 4.2.7.1 Device Status The device status interface is shown as below. See Figure 4-19.  Manufacturer: Here you can view the device manufacturer name.  Product SN: Here you can view the product unique serial number. ...
  • Page 34 Figure 4-19 4.2.7.2 Storage Status The storage status interface is shown as below. See Figure 4-20.  Disk capacity: Here you can view the HDD capacity. The unit is M.  Capacity used: Here you can view the HDD free space percentage. ...
  • Page 35 Figure 4-20 Click the format button, system pops up the following dialogue box. See Figure 4-21. You need to make sure your want to format disk right now since all the data on the HDD will be removed after your format operation. Click OK button to continue or you can click the cancel button to terminate format operation.
  • Page 36 During the format process, you can see an interface is shown as in Figure 4-22. Figure 4-22 After the format operation completed, system pops up the following dialogue box. See Figure 4-23. Please click the OK button to reboot the system.
  • Page 37 Figure 4-23 4.2.7.3 Network Status The network status interface is shown as in Figure 4-24.  Centre server: Here you can view centre server connection status.  FTP server: Here you can view FTP server connection status.  NTP server: Here you can NTP server connection status.
  • Page 38 Figure 4-24 4.2.7.4 Software Information The software information interface is shown as below. See Figure 4-25.  Camera software version: Here you can view camera software version.  Host software version: here you can view the host software compile date.
  • Page 39 Figure 4-25 Click the Upgrade button and insert the upgrade disk in the USB port. Click OK button to continue. You can see system pops up the following dialogue box. See Figure 4-26. Please click the OK button to continue. Figure 4-26 If system can not detect the upgrade disk, system pops up the following dialogue box.
  • Page 40 Please replace upgrade disk and then click the OK button to continue. Figure 4-27 During the upgrade process, the interface is shown as in Figure 4-28. Important Do not terminate the upgrade process once it starts! Figure 4-28 After system completed the upgrade process, system pops up the following dialogue box. See Figure 4-29.
  • Page 41 Important After the upgrade operation, please remove the upgrade disk and then click the OK button to reboot the system! Figure 4-29...

  • Page 42: Faq

    5 FAQ 5.1 About the Touch Panel  Enable screen saver function if the device is running for a long time.  Make sure the touch panel is away from the strong light or direct sunlight.  Do not use the harsh object to click the touch panel. Do not push hard in case the touch panel is physically injured.
  • Page 43  Use the clean soft cloth to clear the dust. Use the air duster to clear the dust and the dry soft cloth to clear the camera.  Use a little detergent to clean the device if there is too much dust.

  • Page 44: Applications

    6 Applications Here are some actual snapshot images for your reference. For privacy reasons, we hide some numbers in the plate. 6.1 Approaching Snapshot in the Daytime The approaching snapshot image in the daytime is shown as in Figure 6-1. Figure 6-1 6.2 Departing Snapshot in the Daytime The departing snapshot image in the daytime is shown as in Figure 6-2.

  • Page 45: Approaching Snapshot At Night

    Figure 6-2 6.3 Approaching Snapshot at Night The approaching snapshot image at night is shown as in Figure 6-3.

  • Page 46: Departing Snapshot At Night

    Figure 6-3 6.4 Departing Snapshot at Night The departing snapshot image at night is shown as in Figure 6-4.
  • Page 47 Figure 6-4 Note  This user’s manual is for reference only. Slight difference may be found in user interface.  All the designs and software here are subject to change without prior written notice.  If there is any uncertainty or controversy, please refer to the final explanation of ours. ...
