Dahua Network Camera Web 3.0 Operation Manual page 90

Dahua Network Camera Web 3.0 Operation Manual
Parameter
Working Period
Record
Record Delay
Relay out
Alarm Delay
Send Email
Audio linkage
Flash linkage
PTZ
Snapshot
Step 3
Click "Save" to complete the setup of video tampering.
5.3.1.3 Scene Changing
Step 1
Select "Setup > Event > Video Detection > Scene Changing" and the system will display the interface of
"Scene Changing" which is shown in
Function
Note:
It is to set the alarm period, it can enable alarm event only during the
period range which has been set.
1. Click "Setup" and the system will pop out the interface of "Working
Period".
2. It is to set working period according to the following methods:

You can input time numerical value or press the left mouse button to
drag on the setup interface to set.

There are six periods to be set every day, select the check box in front
of the period, and then the period is valid.

Select week number (it selects Sunday by default, if it selects the
whole week, then it means the setup can be applied to the whole
week, you can also select the check box in front of the week number
to implement independent setting for some days).
3. Click "Save" to complete the setup of working period.
Check it and so when alarm occurs, system will auto record. You shall set
record period in Storage>Schedule and select auto record in record control
interface.
System can delay the record for specified time after alarm ended. The
value ranges from 10s to 300s.
Enable alarm activation function. You need to select alarm output port so
that system can activate corresponding alarm device when alarm occurs.
System can delay the alarm output for specified time after alarm ended. The
value ranges from 10s to 300s.
If you enabled this function, System can send out email to alert you when
alarm occurs and ends. User can set email address in Network>SMTP.
Check it and the system will play alarm audio file when alarm occurs. Users
can set the recorded or uploaded audio file in "camera setting ＞ audio ＞
alarm audio".
Check it and the flash will be on when alarm occurs, and the flash will
be off until the end of alarm after corresponding delay.

Here you can set PTZ movement when alarm occurs. Such as go to
preset x when there is an alarm.

The event type includes: preset, tour and pattern.
You need to check the box here so that system can backup motion detection
snapshot file. You shall set snapshot period in Storage>Schedule.
Figure 5-58
.
82
