Dahua Network Camera Web 3.0 Operation Manual page 113

Dahua Network Camera Web 3.0 Operation Manual
Parameter
Working Period
Lens Direction
Name
Direction
Flowrate Alarm
Record
Record Delay
Relay out
Alarm Delay
Send Email
Snapshot
Step 6
Click "Save" to complete the setup of people counting.
5.3.6.2 Report
It is to generate a form of report according to the number statistics.
Step 1
Select "Setup > Event > People Counting > Report "and the system will display the interface of "Report',
Figure 5-81
which is shown in
Function
Note:
It is to set the alarm period, it can enable alarm event only during the period
range which has been set.
1. Click "Setup" and the system will pop out the interface of "Working
Period".
2. It is to set working period according to the following methods:

You can input time numerical value or press the left mouse button to
drag on the setup interface to set.

There are six periods to be set every day, select the check box in front
of the period, and then the period is valid.

Select week number (it selects Sunday by default, if it selects the whole
week, then it means the setup can be applied to the whole week, you
can also select the check box in front of the week number to implement
independent setting for some days).
3. Click "Save" to complete the setup of working period.
It is to set image view angle, you can select inclined and vertical.
It is to set rule name.
It is to select the direction of entrance and exit statistics; A->B or B->A, the
arrow direction always means the entrance direction.
It is to set the enter number, leave number, stranded number; it will trigger
alarm when it exceeds the limited number.
Check it and so when alarm occurs, system will auto record.
System can delay the record for specified time after alarm ended.
Enable alarm activation function. You need to select alarm output port so
that system can activate corresponding alarm device when alarm occurs.
System can delay the alarm output for specified time after alarm ended.
If you enabled this function, System can send out email to alert you when
alarm occurs and ends. User can set email address in Network>SMTP.
Select "Snapshot" and the system will auto trigger alarm and snapshot when
alarm occurs.
.
105
