DIGIVEX Little Drive Servoamplifier

1.1 Digital Servodrive

All of the drives comprise:
Brushless servomotors with permanent magnets, sine-wave e.m.f. and resolver-based position
measurement (NX, LX, LS, LD range servomotors)
A box-type electronic control system including:
A power supply function for (depending on the model):
A control function corresponding to the servomotor (power and resolver) for spindle drive motor
control.
This module also controls energy discharge via internal.
Two connection options are available for these servomotors:
Terminal box + resolver connector.
Power connector + resolver connector.

1.2 General Characteristics

Input voltage rating: 230V (see § 4.4.1)
MAINS
TYPE
SUPPLY
230 V –
single-
DLD 2/4
phase
50/60 Hz
230 V –
single-
DLD 4/8
phase
50/60 Hz
230 V –
three-
DLD 2/4
phase
50/60 Hz
230 V –
three-
DLD 4/8
phase
50/60 Hz
230 V –
three-
DLD 7.5/15
phase
50/60 Hz
This manual was downloaded on www.sdsdrives.com
+44 (0)117 938 1800 - info@sdsdrives.com

1. GENERAL

- 230 V single-phase mains supply or 230 V three-phase mains
supply
CONTROLLABLE
POWER
375 W
750 W
375W
750W
1,5kW
7
PVD 3530 GB 01/2005
SINE PEAK PEAK
PERMANENT MAXIMUM
CURRENT CURRENT
2 A
4 A
2 A
4 A
7.5 A 15 A
REF. PARVEX
4 A DLD13M02R
8 A DLD13M04R
4 A DLD13002R
8 A DLD13004R
DLD13007R
