Access via the name of the variable, this is valid for the 16 above plus the following variables:
• Temperature in °C
• Bus voltage in Volts
• Active I in Amps
• Reactive I in Amps
• Id current in Amps
• Iq current in Amps
• Ud voltage in Volts
• Uq voltage in Volts
It should be noticed that these variables can be assigned to the two analog outputs, which
means a separate oscilloscope can be used.

6.3.3 Entering parameters via DIGIVEX PC software

See DIGIVEX PC software instructions:
Choice of rating
Choice of motor (standard or special)
Choice of resolver
Entering servo-control parameters (global transfer)
Assigning inputs / outputs and variables
Use of the oscilloscope function
Use of stimuli function

6.3.4 Setting loop parameters for speed regulation

This can be done by using the "Setting Assistant" menu or directly with the stimuli and
oscilloscope.
Speed for 1 V and maximum speed
The maximum possible speed is set when the motor - drive choice is made.
It can be reduced only here:
Choose a "dc" stimulus of, say, 1 volt.
Check the value obtained for the "measure speed in rpm" variable using the variable observation
or oscilloscope functions.
