DIGIVEX Little Drive Servoamplifier

4.3.2.4 Sub-D connector X3: encoder emulation

Sub-D 9-pin plug. Maximum conductor cross-section: 0.5 mm².

4.3.2.5 Encoder emulation cable

Cable formed from three twisted pairs of 0.14 mm
and general shielding.
Cable reference recommend by PARVEX S.A., CB08307.
Cables equipped with Sub-D connectors can be supplied, see drawing FELX 304554.
This manual was downloaded on www.sdsdrives.com
+44 (0)117 938 1800 - info@sdsdrives.com
CONTACT TYPE
1
2 Output
3 Output
4 Output
5
6 Output
7 Output
8 Output
9 Input
36
PVD 3530 GB 01/2005
FUNCTION
.
Top
0
A
B
Top 0
A
B
0V
2
, of one twisted pair of 0.5 mm
2
for 5 V supply
