DIGIVEX Little Drive Servoamplifier
1.3 Operating Principle
1.3.1 Block diagram
The block diagram shows two parts:
A power supply section providing dc voltage to the power bridge and auxiliary power supplies
(regulation, fans).
one part for axis control and monitoring control.
