DIGIVEX Little Drive Servoamplifier

4.3.2.6 Sub-D connector X4 : RS232

Maximum conductor cross-section: 0.5 mm²
Serial link configuration :
♦ 9600 bauds
♦ 8 data bits
♦ 1 start bit, 1 stop bit
♦ no parity
♦ no electrical isolation
♦ use an extension cable of 5 m maximum
TD (TXD)
RD (RXD)
This input is for linking with a computer (PC) for parameter loading and setting via the DIGIVEX
PC software.

4.4 Connection Details

4.4.1 Main supply characteristics

230 V single-phase or three-phase modules
Frequency
Minimum voltage
Maximum voltage
Rated voltage
Dc voltage achieved
* To guarantee mechanical power
- single or three-phase for 2/4 and 4/8 caliber
- Three-phase only for caliber 7,5/15
This manual was downloaded on www.sdsdrives.com
+44 (0)117 938 1800 - info@sdsdrives.com
SUB-D 9pts DIGIVEX
NC 1
2
3
NC 4
0V 5
NC 6
NC 7
NC 8
NC 9
NC= Not Connected
PARAMETER
PVD 3530 GB 01/2005
SUB-D 9pts PC
1
2
3
4
5
6
7
8
9
VALUE
47 - 63 Hz
92 V rms
253V rms
230V rms *
140 - 340V
38
RD (RXD)
TD (TXD)
0V
