DIGIVEX Little Drive Servoamplifier

4.3.2.2 Sub-D connector X1:"Resolver"

DIGIVEX end connections, Sub-D 9 pin connector item ref. X1.
Maximum conductor cross-section: 0.5 mm²
CONTACT
This manual was downloaded on www.sdsdrives.com
+44 (0)117 938 1800 - info@sdsdrives.com
TYPE
1 Input Cosine S1
2 Input Sine S2
3
Input Cosine S3
4 Input Sine S4
5 Output Excitation R1
6
7
8
9 Output Excite R2/R3
PVD 3530 GB 01/2005
FUNCTION
31
