DIGIVEX Little Drive Servoamplifier

1.3.3.8 Monitoring reasons for stoppage

This monitoring may, through strategic choice, entail either stoppage or reduced performance for
certain faults related to current.
Variables monitored :
Mean drive current.
Output current (short-circuit).
Dissipater temperature.
Motor temperature.
Ambient temperature.
Overspeed.
No resolver.
Maximum and minimum dc bus voltages.

1.3.3.9 General characteristics of the DIGIVEX Little Drive

Power reduction with altitude
Operating temperature
relative humidity
Storage temperature
Chopping frequency
Current bandwidth
Speed bandwidth
Minimum speed
Maximum speed
Speed static precision for load
variation from 0 to In and for
rated voltage of DIGIVEX Little
Drive
Electrical protection
Mechanical protection
Pollution degree
Other monitoring
This manual was downloaded on www.sdsdrives.com
+44 (0)117 938 1800 - info@sdsdrives.com
Above 1000 m, service power falls by 1% for every 100 m up
to a maximum altitude of 4000 m
Normal use: 0 - 40°C
Above 40°C, service power falls by 20% for every 10°C up to
a maximum temperature of 60°C.
The variable speed drive stops when the ambient temperature
exceeds 60°C.
85% (without condensation)
-30°C to +85°C
8 kHz
600Hz to -3dB
Up to 200Hz
Minimum speed 0.05 rpm or 1/8000th of maximum speed
Driven by DIGIVEX : 100 000 rpm
With analog set point: 1% whatever the speed
Electrical isolation of power bridge
Mean current protection depending on drive rating
Pulse current protection of drive and motor
rms current protection of motor
Protection against short circuits at bridge output
IP20 under IEC 529
UL : 2
To rise in a surrounding wall
Motor temperature
Drive temperature
Resolver power supply
Brake supply
15
PVD 3530 GB 01/2005
