4.3.2.3 Sub-D connector X2: Inputs / Outputs

CONTACT TYPE
1 EA1 +
14 EA1 -
2 EA2 +
15 EA2 -
3 SA1
16 0V
4 SA2
17 0V
9 EL1 +
10 EL2 +
11 EL3 +
EA = analog input, EL = logic input, SA = analog output, SL = logic output
This manual was downloaded on www.sdsdrives.com
+44 (0)117 938 1800 - info@sdsdrives.com
FUNCTION
Speed or current set point ±10V,
+ point
Speed or current set point ±10V,
- point
Analog input ±10V, + point
Analog input ±10V, - point
Input assigned to external
current limitation. +/-10V = max.
current
Analog output ±10V, + point
ANA1
0V of analog output
Output assigned to speed
measurement
10V = maximum speed
Analog output ±10V, + point
ANA2
0V of analog output
Output assigned to current
measurement
10V = maximum current
SPEED RANGE
Speed range choice
CW: enables clockwise rotation if
input is active (level 1)
CCW: enables counter-clockwise
rotation if input is active (level 1)
33
PVD 3530 GB 01/2005
CHARACTERISTICS
Analog conversion:
13 bits + sign
Differential input
Analog conversion:
9 bits + sign
Differential input
Analog conversion:
Max. voltage = 10V
Max. current = 10 mA
Protected against
circuits.
Analog conversion:
Max. voltage = 10V
Max. current = 10 mA
Protected against
circuits.
Type-1, optocoupled 24V
logic inputs to IEC 1131-2.
(see characteristics on
following pages)
These inputs must have a 24V
supply to have level 1.
short
short
