4.1.3 DIGIVEX Little Drive Sub-D connectors

In order to ensure the system is free from disturbances, it is essential for the rack to be properly
connected to the earth plane of the electrical cabinet and for the covers of the Sub-D connectors
to be EMI/RFI shielded (metal with shielding braid connection).
Make sure the Sub-D connectors and their covers are properly connected (lock screws fully
tight).
GROUND CONNECTION

4.2 Standard Connection Diagram

See the drawings on the following pages
This manual was downloaded on www.sdsdrives.com
+44 (0)117 938 1800 - info@sdsdrives.com
Fold the shielding braid over the
cable sheath
Solder between the braid and the
green and yellow lead.
