EVAL-M1-05-65D User Manual
iMOTION™ Modular Application Design Kit

Pin assignments

4 Pin assignments
General information about the connectors of the EVAL-M1-05-65D evaluation board is reported. Table 5
includes the details of the line connector J1-AC. It is possible to connect DC voltage to the AC connector. In this
case a permanent DC-current will be conducted through the rectifier bridge. Maximum ratings are valid for AC
as well as DC conditions. It is recommended to observe the temperature of the rectifier bridge. Due to the
rectifier, DC supply's polarity at the connector is of no concern.
The evaluation board doesn't have a fuse. An external fuse is highly recommended during testing.
Table 5 J1- AC Line connector
S. No.
1
2
3
Table 6 denotes the details of the motor side connector J2.
Table 6 J2- Motor side connector
S. No.
1
2
3
User Manual
Pin Details
E Earth ground
L AC line input (120 V – 240 V) or DC+ connector
N AC neutral input or DC- connector
Pin Details
U Connected to motor phase U
V Connected to motor phase V
W Connected to motor phase W
