Bill of Materials of EVAL-M1-05-65D
18 1 LED RED CLEAR ROUND
T/H
19 1 RES SMD 2 kΩ 1% 1/8W
0805
20 1 RES SMD 15.8 Ω 1% 1/8W
0805
21 2 RES SMD 4.7 kΩ 1% 1/8W
0805
22 3 RES SMD 300 Ω 5% 1/4W
1206
23 1 RES SMD 15 kΩ 0.1% 1/8W
0805
24 4 RES SMD 1 kΩ1% 1/8W
0805
25 2 RES SMD 1 M Ω 1% 1/4W
1206
26 1 RES SMD 4.87 kΩ 1% 1/8W
0805
27 6 RES SMD 0 Ω JUMPER
1/8W 0805
28 3 RES 0.25 Ω 1% 3/4W 2010
29 1 NTC 15Ω 9MM DIA
30 17 TEST POINT PC
MINI .040"D WHITE
31 1 IC OFFLINE SWITCHER
32 1 IC REG LINEAR 3.3V 1A
SOT223-4
33 1 IC DUAL DIFF
COMPARATOR 8-SOIC
34 1 IC MOTOR DRIVER 500V
DIP 23
User Manual
LED1 151034RS03000
R1 RC0805FR-072KL
R2 RC0805FR-0715R8L
R3, R5 RC0805FR-074K7L
R4A, R4B, R4C RC1206JR-07300RL
R6 RT0805BRD0715KL
R7, R8, R9, R10 RC0805FR-071KL
R13A, R13B RV1206FR-071ML
R14 (DNP) RC0805FR-074K87L
R22, R23, R24, RC0805JR-070RP
R25, R26, R27
RS1, RS2, RS3 PT2010FK-070R25L
RT1 NTC15D-9
TP1,'TP2, TP22, 5002
TP23,
TP24,TP3,TP4,TP
7,TP13,TP14,TP1
5,TP16,TP17,TP1
8,TP19,TP20,TP2
1
U1 LNK304DN-TL
U2 IFX1117MEV33HTMA
1
U3 LM393ADR
U5 IRSM515-065DA2 /
IRSM505-065DA2
25
Wurth Electronics Inc.
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
SHIN-HANG
KEYSTONE
ELECTRONICS
POWER
INTEGRATIONS
Infineon
Technologies
Texas Instruments
Infineon
Technologies
