Bill of Materials of EVAL-M1-05-65D

7 Bill of Materials of EVAL-M1-05-65D
Table 10 provides the complete bill of materials of the evaluation board.
Table 10 Bill of materials
No Qty Part description
1 1 RECT BRIDGE GPP 4A 600V
GBU
2 1 CAP ALUM 100µF 20%
400V RADIAL
3 9 CAP CER 0.1µF 50V X7R
0805
4 4 CAP CER 1µF 25V X7R 0805
5 1 CAP ALUM 220µF 20% 35V
RADIAL
6 1 CAP CER 10µF 6.3V X5R
0805
7 4 CAP CER 0.012µF 500V X7R
1206
8 1 CAP CER 1000pF 50V
C0G/NP0 0805
9 1 CAP CER 2200pF 50V
C0G/NP0 0805
CAP FILM 0.1UF 10%
10 1
275VAC RADIAL
11 2 CAP CER 2200pF 250VAC
RADIAL
12 2 Diode Standard 600V 1A
Surface Mount SMA
13 1 SERIE 2165S - 5.08 MM -
HORIZONTAL CABLE
ENTRY WITH
RISING CAGE CLAMP - WR-
TBL
14 1 SERIE 2169 - 7.50 MM -
HORIZONTAL CABLE
ENTRY WITH RISING CAGE
CLAMP - WR-TBL
15 1 2.54MM ANGLED DUAL
SOCKET HEADER
16 1 8103-RC
17 1 FIXED IND 2.2mH
THROUGH HOLE
User Manual
Designator Part number
BR1 GBU406
C1 860021380020
C3, C6, C7, C9, 885012207098
C12, C15, C28,
C30, C32
C4, C29, C31, C33 885012207078
C5 860020574012
C8 885012107004
C10, C11, C35, 1206J5000123MDR
C36
C13 885012007063
C14 885012007065
CX1, CX2 890324025017CS
CY1, CY2 DE2E3KY222MN3AM
02F
D1, D2 US1J-13-F
J1 691216510003S
J2 691216910003
J3 613020243121
L1 JWMILLER_8103
L2 RLB0914-222KL
24
Manufacturer
DIODES
INCORPORATED
Wurth Electronics Inc.
Wurth Electronics Inc.
Wurth Electronics Inc.
Wurth Electronics Inc.
Wurth Electronics Inc.
Knowles Syfer
Wurth Electronics Inc.
Wurth Electronics Inc.
Wurth Electronics Inc.
MURATA
ELECTRONICS
Diodes Incorporated
Wurth Electronics Inc.
Wurth Electronics Inc.
Wurth Electronics Inc.
Bourns, Inc.
Bourns Inc.
Revision 2.1
2018-07-09
