Pin assignments
Table 7 provides the pin assignments of the M1 20 pin interface connector J3. This connector is the interface to
the controller board.
Table 7 J3 - 20 pin interface connector for controller board
Pin Name
1 PWMUH
2 GND
3 PWMUL
4 GND
5 PWMVH
6 +3.3V
7 PWMVL
8 +3.3V
9 PWMWH
10 IU+
11 PWMWL
12 IU-
13 GK
14 DCBSENSE
15 VTH
16 IV+
17 IV-
18 IW+
19 IW-
20 VCC
2. Input signals are active high. Pull-down resistors are not inserted on the EVAL-M1-05-65D board and need to be
assembled on control cards. iMOTION™ MADK control cards are already equipped with pull-down resistors.
3. Gate Kill signal (GK) is pulled low during over current condition. Chapter 6.6 explains the details of this circuit.
User Manual
Connectors
3.3 V compatible logic input for high side gate driver-Phase1
Ground
3.3 V compatible logic input for low side gate driver-Phase1
Ground
3.3 V compatible logic input for high side gate driver-Phase2
On board 3.3 V supply
3.3 V compatible logic input for low side gate driver-Phase2
On board 3.3 V supply
3.3 V compatible logic input for high side gate driver-Phase3
Shunt voltage phase U
3.3 V compatible logic input for low side gate driver-Phase3
Ground
Gate kill signal – active low when over current is detected
DC bus positive voltage, scaled in 0-3.3 V range by a voltage divider
Thermistor Output
Shunt voltage phase V
Ground
Shunt voltage phase W
Ground
15 V Supply
11
2
2
2
2
2
2
3
