Pin assignments

4 Pin assignments
General information about the connectors of the Eval-M1-099M evaluation board is described below.
Table 3 and Table 4 include the details of JTAG and UART connectors.
Table 3 J1- UART Connector
S. No. Pin
1 GND
2 RXD
3 TXD
4 +3.3V
Table 4 J2-JTAG Connector
S. No. Pin
1 GND
2 TMS
3 TDO
4 TDI
5 TCK
6 RST
7 +3.3V
8 VPP
Table 5 provides the pin assignments of the iMOTION™ MADK-M1 20 pins interface connector J3. This connector
is the interface to the power board.
Table 5 J3- iMOTION™ MADK-M1 20 pins interface connector for power board
Pin Name
1 PWMUH
2 GND
3 PWMUL
4 GND
5 PWMVH
6 +3.3V
7 PWMVL
8 +3.3V
9 PWMWH
IU+
10
11 PWMWL
12 IU-
13 GK
DCBSENSE
14
Application Note
Details
Ground
Input, Receive data to IRMCK099, can be configured to GPIO pins
Output, Transmit data from IRMCK099, can be configured to GPIO pins
+3.3V power supply
Details
Ground
TMS (test mode)
TDO (data output)
TDI (data input)
TCK (clock)
Not Connected
+3.3V power supply(see Specification for max current)
Input ,OTP Programming voltage (for IRMCK099)
Pin Name Connectors
3.3 V compatible logic output for high side gate driver-Phase U
Ground
3.3 V compatible logic output for low side gate driver-Phase1 U
Ground
3.3 V compatible logic output for high side gate driver-Phase V
On board 3.3 V supply
3.3 V compatible logic output for low side gate driver-Phase V
On board 3.3 V supply
3.3 V compatible logic output for high side gate driver-Phase W
Shunt voltage phase U
3.3 V compatible logic output for low side gate driver-Phase W
Ground
Gate kill signal – active low when over current is detected
DC bus positive voltage, scaled in 0-3.3 V range by a voltage divider
9 <Revision 1.0>
