Pin assignments

4 Pin assignments
General information about the connectors of the EVAL-M1-05F804 evaluation board is reported.
Table 5 Include the details of the DC input connector J4-DC.
Table 6 denotes the details of the motor side connector J1.
Table 5 J4- DC input connector
S. No. Pin
1 GND
2 DCP
Table 6 J1- Motor side connector
S. No. Pin
1
2
3 W
Table 7 provides the pin assignments of the iMOTION™ MADK-M1 20 pin interface connector J3. This connector
is the interface to the power board.
Table 7 J2- iMOTION™ MADK-M1 20 pin interface connector for power board
Pin Name
1 PWMUH
2 GND
3 PWMUL
4 GND
5 PWMVH
6 +3.3V
7 PWMVL
8 +3.3V
9 PWMWH
10 IU+
11 PWMWL
12 IU-
13 GK
14 DCBSENSE
15 VTH
16 IV+
17 IV-
18 IW+
19 IW-
20 VCC
User Manual
Details
DC - connector
DC + connector
Details
U Connected to motor phase U
V Connected to motor phase V
Connected to motor phase W
Pin Name Connectors
3.3 V compatible logic input for high side gate driver-Phase U
Ground
3.3 V compatible logic input for low side gate driver-Phase U
Ground
3.3 V compatible logic input for high side gate driver-Phase V
3.3V power supply
3.3 V compatible logic input for low side gate driver-Phase V
3.3V power supply
3.3 V compatible logic input for high side gate driver-Phase W
Shunt voltage phase U
3.3 V compatible logic input for low side gate driver-Phase W
Ground
Gatekill
Input, DC bus voltage to AIN1 after 2Mohm registers
Input, Voltage input of Power Module's Temperature sense
Shunt voltage phase V
Ground
Shunt voltage phase W
Ground
Defined for 15 V Power Supply
