EVAL-M1-05-65D User Manual
iMOTION™ Modular Application Design Kit
Schematics and Layout
The top layer of the PCB is provided in Figure 18.
Figure 18
Top layer of the EVAL-M1-05-65D
Figure 19 illustrates the bottom layer routing of the PCB.
Figure 19
Bottom layer routing of the EVAL-M1-05-65D
