5.2.2 1-0* General Settings
Define whether the frequency converter operates in open
loop or closed loop.
1-00 Configuration Mode
Option: Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
[0] Open Motor speed is determined by applying a speed
Loop reference or by setting desired speed when in
Hand Mode.
Open Loop is also used if the frequency converter
is of a closed loop control system based on an
external PID controller providing a speed reference
signal as output.
[3] Closed Motor Speed will be determined by a reference
Loop from the built-in PID controller varying the motor
speed as of a closed loop control process (e.g.
constant pressure or flow). The PID controller must
be configured in parameter group 20-** Feedback
or via the Function Set-ups accessed by pressing
[Quick Menus].
NOTICE
When set for Closed Loop, the commands Reversing and
Start Reversing do not reverse the direction of the
motor.
1-20 Motor Power [kW]
Range: Function:
Size [ 0.09 - Enter the nominal motor power in kW
related 2000.00 according to the motor nameplate data.
*
kW] The default value corresponds to the
nominal rated output of the unit.
Depending on the choices made in
0-03 Regional Settings, either
parameter 1-20 Motor Power [kW] or
1-21 Motor Power [HP] is made invisible.
1-22 Motor Voltage
Range: Function:
Size [ 10 - Enter the nominal motor voltage
related 1000 V] according to the motor nameplate
*
data. The default value corresponds to
the nominal rated output of the unit.
1-23 Motor Frequency
Range: Function:
Size [20 - Select the motor frequency value from the
related 1000 motor nameplate data. For 87 Hz operation
*
Hz] with 230/400 V motors, set the nameplate
VLT AQUA Drive FC 202 Operation Instructions
1-23 Motor Frequency
Range:
1-24 Motor Current
Range:
Size
related
*
1-25 Motor Nominal Speed
Range:
Size related
1-29 Automatic Motor Adaptation (AMA)
Option:
[0] Off
[1] Enable
Complete
AMA
[2] Enable
Reduced AMA
NOTICE
Parameter 1-29 Automatic Motor Adaptation (AMA) have
no effect when 1-10 Motor Construction = [1] PM, non
salient SPM.
Activate the AMA function by pressing [Hand on] after
selecting [1] or [2]. See also the item Automatic Motor
Adaptation in the Design Guide. After a normal sequence,
the display reads: Press [OK] to finish AMA. After pressing
[OK], the frequency converter is ready for operation.
MG20P402 - Rev. 2013-12-16
Function:
data for 230 V/50 Hz. Adapt
parameter 4-13 Motor Speed High Limit [RPM]
and 3-03 Maximum Reference to the 87 Hz
application.
Function:
[ 0.10 - Enter the nominal motor current
10000.00 A] value from the motor nameplate
data. This data is used for
calculating motor torque, motor
thermal protection etc.
Function:
[100 - 60000 Enter the nominal motor speed
*
RPM] value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
No function
Performs AMA of the stator resistance R
rotor resistance R , the stator leakage
r
reactance X , the rotor leakage reactance X
1
and the main reactance X
Performs a reduced AMA of the stator
resistance R in the system only. Select this
s
option if an LC filter is used between the
frequency converter and the motor.
